Volvo D13M-375
Built: 2017-2017 · Series: Other models
More machines from model year 2017
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The D13M-375 comes from Volvo. Production: 2017. The fuel is 7-15 ppm ultra low sulfur diesel. The rated output is 375 hp. The engine is turbocharged. It is a diesel engine. Rated output across the Volvo range ranges from 325 to 605 kW; the D13M-375 sits in the lower part of that range with 375 kW. Its immediate neighbours are the MP7-365M below it with 365 kW and the D11H-385 above it with 385 kW. 5366 Volvo models across 29 series are on record. The model is listed under Heavy-duty on-road engines. 20 verified figures from 1 source are on file.
Volvo – other heavy-duty highway diesel engines: the collective page of the D11/D11H/D13 ranges from 325 to 564 kW, model years 2012 to 2026, long-haul engines from North America
This page gathers the versions certified in the EPA register directly under the Volvo name, represented here, alongside the D11 and D13 ranges, by the D11H designation; the H suffix denotes, by manufacturer logic, an older or lighter version of the 10.8-litre D11 range. Model years span 2012 to 2026, covering the full production run of the current D11/D13 generation since its introduction; type designations combine range and rated output in horsepower, as with the other Volvo engines.
Read on 3 more paragraphs
The register lists here 76 versions with 325 to 564 kW rated output at 1,450 to 1,900 rpm; displacement of 10.8 to 12.8 litres is recorded for 62 of the 76 versions. Maximum torque ranges from 1,215.3 to 2,122 Nm at 1,000 to 1,200 rpm. Classic direct injection (62 versions) sits alongside electronic direct injection (14 versions) on older certifications; 62 versions are approved for tractor and vocational use, 14 fall into the separate heavy heavy-duty diesel (HHDD) category.
With rated output up to 564 kW, this collective page also covers the most powerful versions of the D13 range ever certified, designed chiefly for heavy-haul and long-distance service at high gross weight. Volvo thereby positions itself in the North American market against the top-output engines from Cummins, Detroit Diesel and Paccar.
On the older, electronically direct-injected versions the injection pump's history matters, on the newer common-rail versions the condition of the injectors and high-pressure pump; consistently important throughout is the service history of exhaust gas recirculation, diesel particulate filter and SCR catalyst, plus turbocharger condition. Spare parts and diagnostics run through the Volvo Trucks dealer network.
Sources: Kennwerte der Modelle Volvo (weitere Heavy-Duty-Strassenmotoren), Volvo Trucks (Volvo Group, Hersteller)
Technical data
Engine
| Engine code | Vcorrect |
|---|---|
| Engine family | KVPTH12.8G01; JVPTH12.8G01; HVPTH12.8G01correct |
| Engine families | KVPTH12.8G01; JVPTH12.8G01; HVPTH12.8G01correct |
| Fuel | 7-15 ppm ultra low sulfur dieselcorrect |
| Rated output | 375 hpcorrect |
| Rated speed | 1,700 rpmcorrect |
| Maximum torque | 1,499 ft·lbfcorrect |
| Speed at max. torque | 1,000 rpmcorrect |
| Displacement | 12,800 cm³correct |
| Displacement | 12.8 lcorrect |
| Operating cycle | dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
Origin and approval
| Version | Vcorrect |
|---|---|
| Built from | 2017correct |
| Built to | 2019correct |
| Model year from | 2017correct |
| Model year to | 2019correct |
Other data
| Anwendungsbereich | Both Tractor and Vocationalcorrect |
|---|
Frequently asked questions
How much power does the Volvo D13M-375 have?
The Volvo D13M-375 delivers 375 kW.
What engine does the Volvo D13M-375 have?
12,800 cm³ displacement, 7-15 ppm ultra low sulfur diesel.
When was the Volvo D13M-375 built?
Production years: 2017.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 21 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
D11H-325
D11H-355
D11H-365
D11H-385
D11H-405
D11M-325
D11M-355
D11M-365
D11M-385
D11M-425
D11N-325
D11N-355
Sources: [1]
Diesel engine in 3D section
Turn the model, look inside and click an assembly — each one is explained.
Parts for this engine (57)
Manufacturer part numbers from the official EPA documentation. No prices or availability — those come from the supplier.
| Teilenummer | Bezeichnung | Hersteller |
|---|---|---|
| 22449432 | Aftertreatment Control Module (ACM) | Volvo |
| 23252913 | Aftertreatment Control Module (ACM) | Volvo |
| 23937771 | Aftertreatment Hydrocarbon Injector (AHI) Injector | Volvo |
| 21718154 | Crankcase Breather | Volvo |
| 22744063 | DEF Injector (dosing valve) - "Onebox" EATS arrangement;DEF Injector (dosing valve) - "Onebox" EATS arrangement;DEF Injector - 1-Box;DEF Injector - 1-Box;DEF Injector (dosing valve) - "Onebox" EATS arrangement | Volvo |
| 22757148 | DEF Injector (dosing valve);DEF Injector - 2-Box;DEF Injector (dosing valve);DEF Injector (dosing valve);DEF Injector - 2-Box;DEF Injector;DEF Injector - Linear (1-Box) | Volvo |
| 24326552 | DEF Pump assembly (Pump Unit);DEF Pump assembly (Pump Unit);DEF Pump Assembly;DEF Pump Assembly;DEF Pump assembly (Pump Unit);DEF Pump Assembly | Volvo |
| 85002754 | DEF Pump assembly (Pump Unit), Remanufactured | Volvo |
| 85031447 | DEF Pump assembly (Pump Unit), Remanufactured | Volvo |
| 22058297 | DPF Assembly with Diesel Oxidation Catalyst (DOC) - Right side Horizontal, under cab;DPF Assembly with Diesel Oxidation Catalyst (DOC) - Right side Horizontal, under cab;DPF Assembly with Diesel Oxidation Catalyst (DOC) - Horizontal;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly with Diesel Oxidation Catalyst (DOC) - Right side Horizontal, under cab;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly with Diesel Oxidation Catalyst (DOC) - Right side Horizontal, under cab | Volvo |
| 24771668 | DPF Assembly with Diesel Oxidation Catalyst (DOC) - Right side Horizontal, under cab;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly with Diesel Oxidation Catalyst (DOC) - Right side Horizontal, under cab;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly, w/ DOC - Compact, 2-Box;DPF Assembly with Diesel Oxidation Catalyst (DOC) - 2-Box, Compact;DPF Assembly with Diesel Oxidation Catalyst (DOC) - Right side Horizontal, under cab | Volvo |
| 24405156 | Sensor DPF Differential Pressure | Volvo |
| 23488881 | Sensor DPF Differential Pressure | Volvo |
| 21946977 | EGR Control Valve (VCB Valve) | Volvo |
| 23507543 | EGR Control Valve (VCB Valve);EGR Valve (VCB);EGR Control Valve (VCB Valve);EGR Valve (VCB);EGR Valve (VCB);EGR Control Valve (VCB Valve) | Volvo |
| 23225749 | EGR Cooler | Volvo |
| 22721861 | EGR Valve | Volvo |
| 22581042 | Engine Control Module (ECM) | Volvo |
| 23141251 | Engine Control Module (ECM) | Volvo |
| 23166751 | Engine Control Module (ECM) | Volvo |
| 24400053 | Engine Control Module (ECM) | Volvo |
| 22172068 | Sensor EGR Differential Pressure | Volvo |
| 22076519 | Intake Throttle Valve | Volvo |
| 22942010 | Intake Throttle Valve | Volvo |
| 22303390 | Sensor NOx (Pre-cat);Sensor NOx - SCR In;Sensor NOx - SCR In;Sensor NOx (Pre-cat);Sensor NOx (Pre-cat);Sensor NOx - SCR In | Volvo |
| 22303391 | Sensor NOx (Post-cat);Sensor NOx - SCR Out, 2-Box;Sensor NOx - SCR Out, 2-Box;Sensor NOx (Post-cat);Sensor NOx (Post-cat);Sensor NOx - SCR Out, 2-Box | Volvo |
| 85023783 | Sensor NOx (Pre-cat), Remanufactured | Volvo |
| 22983179 | SCR "blanket" Heat Shield (bottom) - on 2-box EATs configs only | Volvo |
| 22976169 | SCR "blanket" Heat Shield (lower) - on 2-box EATs configs only | Volvo |
| 22976166 | SCR "blanket" Heat Shield (upper) - on 2-box EATs configs only | Volvo |
| 23196228 | SCR Assembly (2-Box);SCR Assembly - 2-Box, Vertical;SCR Assembly - Vertical, Bottom Inlet, 2-Box;SCR Assembly - Vertical, Bottom Inlet, 2-Box;SCR Assembly - 2-Box, Vertical;SCR Assembly (2-Box);SCR Assembly - 2-Box, Vertical;SCR Assembly - Vertical, Bottom Inlet, 2-Box;SCR Assembly - Vertical, Bottom Inlet, 2-Box;SCR Assembly (2-Box);SCR Assembly - 2-Box, Vertical;SCR Assembly - Vertical, Bottom Inlet, 2-Box;SCR Assembly - 2-Box, Vertical;SCR Assembly (2-Box) | Volvo |
| 21970118 | SCR Assembly (1-Box) | Volvo |
| 22058301 | SCR Assembly (2-Box);SCR Assembly (2-Box);SCR Assembly - Vertical arrangement;SCR Assembly - Vertical arrangement;SCR Assembly (2-Box) | Volvo |
| 23159384 | SCR Assembly (1-Box);SCR and DPF Assembly - 1-Box;SCR and DPF Assembly - 1-Box;SCR Assembly (1-Box);SCR and DPF Assembly - 1-Box;SCR Assembly - 1-Box;SCR Assembly (1-Box) | Volvo |
| 23189992 | SCR Assembly (1-Box) | Volvo |
| 23190004 | SCR Assembly (2-Box) | Volvo |
| 24776391 | SCR Assembly (1-Box);SCR and DPF Assembly - 1-Box;SCR and DPF Assembly - 1-Box;SCR Assembly (1-Box);SCR and DPF Assembly - 1-Box;SCR Assembly (1-Box);SCR Assembly - 1-Box | Volvo |
| 21164414 | Sensor Post-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Pre-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Post-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor DPF Downstream Temperature;Sensor Post-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Post-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Post-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Post-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Pre-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DPF (T2) - 2-Box;Sensor Post-Catalyst Temperature | Volvo |
| 22899626 | Sensor AHI Fuel Pressure | Volvo |
| 22422785 | Sensor Inlet Manifold Temperature, Pressure;Sensor Temperature & Pressure Inlet Manifold Air | Volvo |
| 22303384 | Sensor NOx (Post-cat) - "Onebox" EATS arrangement;Sensor NOx - SCR Out, 1-Box;Sensor NOx - SCR Out, 1-Box;Sensor NOx (Post-cat) - "Onebox" EATS arrangement;Sensor NOx (Post-cat) - "Onebox" EATS arrangement;Sensor NOx - SCR Out, 1-Box | Volvo |
| 85023785 | Sensor NOx (Post-cat) - "Onebox" EATS arrangement, Remanufactured | Volvo |
| 85023784 | Sensor NOx (Post-cat), Remanufactured | Volvo |
| 24307015 | Sensor Particulate Matter (PM) | Volvo |
| 21225020 | Sensor DPF Downstream Temperature;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor DPF Downstream Temperature;Sensor Pre-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Pre-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Pre-Catalyst Temperature;Sensor Temperature, Post-SCR (T4) - Linear (1-Box);Sensor Pre-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Pre-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Post-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor DPF Downstream Temperature;Sensor Pre-Catalyst Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Pre-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Pre-Catalyst Temperature;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Post-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Pre-Catalyst Temperature;Sensor Pre-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor DPF Downstream Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor DPF Downstream Temperature;Sensor Post-Catalyst Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DPF (T2) - 1-Box;Sensor DPF Downstream Temperature;Sensor Temperature, Pre-DOC (T1) - 2-Box;Sensor Temperature, Pre-DPF (T2) - 1-Box | Volvo |
| 24382877 | Sensor Urea Quality and Level (UQLS) - 25L Tank Applications;Sensor Urea Quality and Level (UQLS) - 25L;Sensor Urea Quality and Level (UQLS) - 25L Tank Applications;Sensor Urea Quality and Level (UQLS) - 25L Tank Applications;Sensor Urea Quality and Level (UQLS) - 25L;Sensor Urea Quality and Level (UQLS) - 25L;Sensor Urea Quality and Level (UQLS) - 25L Tank Applications;Sensor Urea Quality (UQS) - 25L Tank Applications | Volvo |
| 24382983 | Sensor Urea Quality and Level (UQLS) - 33L Tank Applications;Sensor Urea Quality and Level (UQLS) - 33L Tank Applications;Sensor Urea Quality and Level (UQLS) - 33L;Sensor Urea Quality and Level (UQLS) - 33L;Sensor Urea Quality and Level (UQLS) - 33L Tank Applications;Sensor Urea Quality and Level (UQLS) - 33L;Sensor Urea Quality (UQS) - 33L Tank Applications;Sensor Urea Quality and Level (UQLS) - 33L Tank Applications | Volvo |
| 24383039 | Sensor Urea Quality and Level (UQLS) - 45L Tank Applications;Sensor Urea Quality and Level (UQLS) - 45L;Sensor Urea Quality and Level (UQLS) - 45L Tank Applications;Sensor Urea Quality and Level (UQLS) - 45L Tank Applications;Sensor Urea Quality and Level (UQLS) - 45L;Sensor Urea Quality and Level (UQLS) - 45L;Sensor Urea Quality and Level (UQLS) - 45L Tank Applications;Sensor Urea Quality (UQS) - 45L Tank Applications | Volvo |
| 24383068 | Sensor Urea Quality and Level (UQLS) - 70L Tank Applications;Sensor Urea Quality and Level (UQLS) - 70L;Sensor Urea Quality and Level (UQLS) - 70L Tank Applications;Sensor Urea Quality and Level (UQLS) - 70L Tank Applications;Sensor Urea Quality and Level (UQLS) - 70L;Sensor Urea Quality and Level (UQLS) - 70L;Sensor Urea Quality (UQS) - 70L Tank Applications;Sensor Urea Quality and Level (UQLS) - 70L Tank Applications | Volvo |
| 22891440 | Turbocharger Assembly | Volvo |
| 24011183 | Turbocharger Assembly;Turbocharger (VGT);Turbocharger Assembly;Turbocharger Assembly;Turbocharger (VGT);Turbocharger (VGT) | Volvo |
| 22378580 | Unit Injectors Non-Pumping | Volvo |
| 85022899 | Unit Injectors Non-Pumping, Remnaufactured;Unit Injectors Non-Pumping, Remanufactured;Unit Injectors Non-Pumping, Remnaufactured;Unit Injectors Non-Pumping, Remnaufactured;Unit Injectors Non-Pumping, Remanufactured | Volvo |
| 22378579 | Unit Injectors Pumping | Volvo |
| 23771407 | Unit Injectors Pumping | Volvo |
| 85022897 | Unit Injectors Pumping, Remanufactured | Volvo |
| 85023400 | Unit Injectors Pumping, Remanufactured | Volvo |
Quelle: EPA HD Engines 2015–Present
