Start › Wheel loaders › Volvo › L330C

Volvo L330C

Series: Volvo Wheel Loader

Source: https://commons.wikimedia.org/wiki/File:Volvo-L90E-Radlader2

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo L330C is a model in the Volvo Wheel Loader series. The engine delivers 510 hp (371.4 kW), has 6 cylinders, with a displacement of 16,124.9 cm³. Torque is 2,370 Nm. Rated speed is 1,800 rpm. The unladen weight is 48,430.1 kg. The wheelbase measures 4,063 mm. Ground clearance is 551.7 mm. The tank holds 693.1 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,000 rpm. The pump delivers 741.9 l/min. The hydraulic tank holds 552.3 litres. The cooling system holds 90.1 litres. The electrical system runs on 24 V. The engine fitted is the TD 164 KAE. Tyre size: 35/65R33 XLD D1*L-4. The Volvo Wheel Loader series covers 83 models. Rated output within it ranges from 31.4 to 539.4 hp; the L330C sits at the top of that range with 510 hp. Its immediate neighbours are the L260H below it with 421.8 hp and the L350H above it with 539.4 hp. 5366 Volvo models across 29 series are on record. The model is listed under Wheel loaders. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine modelTD 164 KAEcorrect
Power510 hp (371.4 kW)correct
Rated speed1,800 rpmcorrect
Torque2,370correct
Speed at max. torque1,000 rpmcorrect
Cylinders6correct
Displacement16,124.9 cm³correct
AspirationTurbocharged and Intercooledcorrect
Coolant capacity90.1 lcorrect

Dimensions and weights

Wheelbase4,063correct
Ground clearance551.7correct
Unladen weight48,430.1 kgcorrect

Drivetrain and chassis

Gearbox typePower shiftcorrect
Forward gears4correct
Reverse gears3correct
Tyre size35/65R33 XLD D1*L-4correct
System voltage24 Vcorrect

Working data

Pump flow741.9 l/mincorrect
Hydraulic oil capacity552.3 lcorrect
Fuel tank capacity693.1 lcorrect

Other data

Height4,172.7correct

Where this model stands

Power-to-weight ratio: 7.7 kW/t (371 kW / 48.4 t)

Stronger than 97% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo L330C have?

The Volvo L330C delivers 510 hp.

How much does the Volvo L330C weigh?

The unladen weight is 48,430 kg.

What engine does the Volvo L330C have?

6 cylinders, 16,125 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
