Volvo L120E

Series: Volvo Wheel Loader

Source: https://used.robert-aebi.de/robertaebi/baumaschinen/radlader

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the L120E, Volvo offers a model from the Volvo Wheel Loader series. The engine delivers 227.1 hp (166.3 kW), has 6 cylinders, with a displacement of 7,100.5 cm³. Torque is 1,020.1 Nm. Rated speed is 1,800 rpm. The unladen weight is 18,960 kg. The wheelbase measures 3,200.4 mm. Ground clearance is 402.3 mm. The tank holds 215 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 145.4 l/min. The hydraulic tank holds 143.1 litres. The cooling system holds 70 litres. The electrical system runs on 24 V. The engine fitted is the D7D LA E2. Tyre size: 23,5R25 L3. The Volvo Wheel Loader series covers 83 models. Rated output within it ranges from 31.4 to 539.4 hp; the L120E sits in the lower part of that range with 227.1 hp. Its immediate neighbours are the L120D below it with 210.9 hp and the L110E above it with 231.2 hp. 5366 Volvo models across 29 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD7D LA E2correct
Power227.1 hp (166.3 kW)correct
Rated speed1,800 rpmcorrect
Torque1,020.1correct
Speed at max. torque1,400 rpmcorrect
Cylinders6correct
Displacement7,100.5 cm³correct
Coolant capacity70 lcorrect

Dimensions and weights

Wheelbase3,200.4correct
Ground clearance402.3correct
Unladen weight18,960 kgcorrect

Drivetrain and chassis

Gearbox typeVolvo HTE205correct
Forward gears4correct
Reverse gears4correct
Tyre size23.5R25 L3correct
System voltage24 Vcorrect

Working data

Pump flow145.4 l/mincorrect
Hydraulic oil capacity143.1 lcorrect
Fuel tank capacity215 lcorrect

Other data

Height3,361.9correct

Where this model stands

Power-to-weight ratio: 8.8 kW/t (166 kW / 19 t)

Stronger than 79% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Volvo L120E have?

The Volvo L120E delivers 227 hp.

How much does the Volvo L120E weigh?

The unladen weight is 18,960 kg.

What engine does the Volvo L120E have?

6 cylinders, 7,100 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
