Volvo BL60

Series: Volvo Loader Backhoe

Source: https://www.technikboerse.at/gebraucht/radlader-255/volvo-12

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Volvo BL60 is a model in the Volvo Loader Backhoe series. The engine delivers 61.9 kW, has 4 cylinders, with a displacement of 4,041 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,164.1 mm. Ground clearance is 347.5 mm. The tank holds 120 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,500 rpm. The pump delivers 115.8 l/min. The hydraulic tank holds 110.2 litres. Working pressure is 36.3 bar. The cooling system holds 18.9 litres. The electrical system runs on 12 V. The engine fitted is the D4D. The Volvo Loader Backhoe series covers 5 models. Rated output within it ranges from 59.7 to 70 kW; the BL60 sits in the lower part of that range with 61.9 kW. Its immediate neighbours are the 616 below it with 59.7 kW and the BL70 above it with 67.1 kW. 5366 Volvo models across 29 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD4Dcorrect
Power61.9 kWcorrect
Rated speed2,200 rpmcorrect
Speed at max. torque1,500 rpmcorrect
Cylinders4correct
Displacement4,041 cm³correct
Aspirationturbochargedcorrect
Coolant capacity18.9 lcorrect

Dimensions and weights

Wheelbase2,164.1correct
Ground clearance347.5correct

Drivetrain and chassis

Gearbox typePowershuttle gear boxcorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow115.8 l/mincorrect
Hydraulic oil capacity110.2 lcorrect
Hydraulic pressure36.3correct
Fuel tank capacity120 lcorrect

Frequently asked questions

How much power does the Volvo BL60 have?

The Volvo BL60 delivers 61.9 kW.

What engine does the Volvo BL60 have?

4 cylinders, 4,041 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 18 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
