Volkswagen SDX0AE
Built: 2005-2005 · Series: Vans up to 3.5 t (Class N1)
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Volkswagen Transporter — Crafter was a Mercedes Sprinter in disguise until 2016
Volkswagen groups several very different ranges under the Transporter name, all under 3.5 tonnes: the compact Caddy, the actual Transporter across the T5, T6, T6.1 and the newest generation delivered since February 2025, and the larger Crafter. The key technical distinction concerns the Crafter: the first generation, built from 2006 to November 2016, was essentially a Mercedes-Benz Sprinter wearing a VW badge, built jointly with Mercedes at the Düsseldorf and Ludwigsfelde plants. The second generation, on sale from 2017, is an independent Volkswagen design, built at a newly constructed factory in Września, Poland. Telling the ranges apart therefore requires checking both size and build year.
Read on 3 more paragraphs
The Caddy is the most compact range, with a gross vehicle weight of roughly 2,150 to 2,450 kilograms depending on body style — Caddy, Caddy Kombi or Caddy Maxi. It shares its floor platform with the Golf and is mostly used for smaller deliveries and as a tradesperson's vehicle. The classic Transporter, in its T5, T6 and T6.1 generations, covered the mid-size class for decades and was built in Hanover. Its direct successor, delivered since February 2025, is technically no longer an independent Volkswagen design — it is built on the Ford Transit Custom platform, alongside that model, at the Ford Otosan plant in Turkey, with Volkswagen contributing mainly the interior and body detailing.
The Crafter is the largest range, offered in the Crafter 30 (around 3 tonnes), Crafter 35 (3.5 tonnes) and Crafter 50 (5 tonnes) weight classes. The 5-tonne version therefore exceeds the upper limit of the N1 category and is formally classed as N2. Orders for the second-generation Crafter opened in November 2016, with the first deliveries following in March 2017. Before that, the Crafter differed from the Sprinter externally in little more than the front end, tail lights and engines fitted.
When buying a used Crafter, generation is the decisive difference: vehicles up to model year 2016 are technically equivalent to the second-generation Sprinter, so some spare and wear parts can be swapped between the two brands. The Crafter from 2017 onward has its own design and its own parts structure at Volkswagen, incompatible with the older Sprinter. It is worth checking the exact production date and chassis number before buying, not just the exterior look. A similar point now applies to the newest Transporter: buying one means technically buying a Ford-based vehicle, even though sales, servicing and warranty run through Volkswagen.
Sources: Wikipedia: VW Crafter (Generationen, Werke, Zeiträume), MeinAuto.de: VW Caddy technische Daten, amz.de: neuer VW Transporter basiert auf Ford Transit Custom, Wikipedia: Volkswagen Transporter (2024), Produktion Ford Otosan Türkei, Marktstart Februar 2025
Technical data
Engine
| Cylinders | 5correct |
|---|---|
| Displacement | 2,461 cm³correct |
Dimensions and weights
| Width | 1,910 mmcorrect |
|---|---|
| Wheelbase | 4,030 mmcorrect |
| Unladen weight | 2,150 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|
Frequently asked questions
How much does the Volkswagen SDX0AE weigh?
The unladen weight is 2,150 kg.
What is the gross vehicle weight of the Volkswagen SDX0AE?
3,500 kg.
What engine does the Volkswagen SDX0AE have?
5 cylinders, 2,461 cm³ displacement.
When was the Volkswagen SDX0AE built?
Production years: 2005.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
