Van Eck P T-1 B I
Built: 2008-2008 · Series: Trailers over 10 t (Class O4)
More machines from model year 2008
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Van Eck trailers over 10 t (Class O4) – type codes with CM/CT/DA/DM/DT prefixes and special bodies such as ECK-COOL: 204 versions in the EU heavy-haulage class, unladen weights 2,820 to 18,540 kg, lengths up to 14.05 m
Class O4 groups trailers with a permissible gross weight over 10 tonnes, as recorded in registration data from the Netherlands and Finland. At Van Eck, type designations visibly follow a scheme of two letters plus a running number – CM, CT, DA, DM and DT recur repeatedly and likely denote a chassis or axle variant. Alongside these are special names such as ECK-COOL, pointing to a refrigerated body, ECK PLY for a plywood-floor version, and DOLLY for lead axles used to extend semi-trailers into multi-part combinations.
Read on 3 more paragraphs
The register lists 204 versions with unladen weights from 2,820 to 18,540 kg and permissible gross weights from 11,520 to 45,000 kg. Lengths are recorded for 170 of the 204 vehicles and range from 6,050 to 14,050 mm, width for all 204 versions from 2,400 to 2,600 mm.
The narrow width span of just 200 mm, combined with a wide length span, points to a programme strongly geared towards container and swap-body transport as well as classic flatbed and refrigerated trailers, with a standardised vehicle width across almost all sizes.
For a used trailer of this type, check frame corrosion on chassis rails, the condition of axles and the EBS braking system, the function of the air suspension, and wear and locking of container twist-locks where fitted. For refrigerated bodies, add the tightness of the insulated box and the condition of the refrigeration unit; for dollies, the drawbar eye and coupling as well. A complete inspection history matters especially for special bodies, since parts are often only available through the Dutch commercial-vehicle trade.
Sources: Kennwerte der Modelle Van Eck Anhänger über 10 t (Klasse O4)
Technical data
Dimensions and weights
| Length | 10,750 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 6,870 mmcorrect |
| Unladen weight | 7,100 kgcorrect |
| Gross vehicle weight | 25,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Van Eck P T-1 B I weigh?
The unladen weight is 7,100 kg.
What is the gross vehicle weight of the Van Eck P T-1 B I?
25,000 kg.
Up to what speed is the Van Eck P T-1 B I approved?
Approved up to 100 km/h.
What are the dimensions of the Van Eck P T-1 B I?
10,750 mm × 2,550 mm.
When was the Van Eck P T-1 B I built?
Production years: 2008.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
