Trojan MD1C315M-4

Series: Other models

Source: https://www.allied-automation.com/00318nt3fvd182tc-w22.html

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

Trojan lists the MD1C315M-4 as a three-phase induction motor. The rated output is 132 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 415 V. The housing is frame size 315 M in foot-mounted form. The protection class is IP55. The efficiency is 94.6 per cent at full load, 93 per cent at 75 per cent load and 93 per cent at half load. The motor weighs 1,175 kg. At full load it delivers 849 Nm. Mounting arrangements to IEC 60034-7: B3 and B5. The motor is built in China. The figures come from the Australian MEPS register under standard AS/NZS 1359.5:2000 (Legacy); measured to AS/NZS 1359.102.3:2000. Rated output across the Trojan range ranges from 0.75 to 200 kW; the MD1C315M-4 sits in the upper part of that range with 132 kW. Its immediate neighbours are the MD1C315S-4 below it with 110 kW and the 160C315LA-2 above it with 160 kW. 286 Trojan models are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.

Technical data

Engine

Rated output132 kWcorrect

Dimensions and weights

Weight1,175 kgcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles4correct
Protection classIP55correct
Frame size315 M (foot)correct
Mounting (IEC 60034-7)B3, B5, B5/B3correct
Efficiency at full load94.6 %correct
Efficiency at 75 % load93 %correct
Efficiency at half load93 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedAS/NZS 1359.5:2000 (Legacy)correct
Test methodAS/NZS 1359.102.3:2000correct

Frequently asked questions

How much power does the Trojan MD1C315M-4 have?

The Trojan MD1C315M-4 delivers 132 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
