Trojan MD1A100L2-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Trojan – other models: the collective page of three-phase motors from the Australian GEMS/MEPS register, 0.75 to 200 kW, 2- to 8-pole, IP55 throughout, Chinese manufacture, efficiencies up to 95.6%
This page gathers the three-phase motors registered under the Trojan brand in the Australian GEMS/MEPS register that could not be assigned to a named range. Nothing certain can be inferred from the register about Trojan's headquarters or group ownership; what is confirmed is that every model recorded here comes from Chinese manufacture. The type codes follow a recognisable pattern of power rating, range letter, IEC frame size and pole count – for instance 0.75C80A-2 for a 0.75 kW motor of the C range in frame 80A with two poles, or MD1A/MD1C as distinct range prefixes – but the precise technical meaning of the individual letters beyond the frame size cannot be reliably reconstructed from the register.
Read on 3 more paragraphs
The register lists here 286 versions from 0.75 to 200 kW, 2- to 8-pole, with efficiencies from 70.5 to 95.6% at full load and 70 to 99.2% at 75% load, all in protection class IP55 and frame sizes from 80 (IEC) upwards. No GEMS "High Efficiency Level" classification is recorded for any of the 286 models.
With a power span reaching 200 kW, the brand also covers larger drive ratings than many other parts of the register in this size class; without confirmed manufacturer information, Trojan's market role can only be read from the register data itself – as a supplier of consistently IP55-rated standard motors for the Australian and New Zealand market.
For used Trojan motors, the usual checkpoints for standard motors apply: measure the winding's insulation resistance, check the bearings for running noise and play, check the shaft turns freely, assess the condition of the fan and fan cowl, and match the rating plate – frame size, pole count and efficiency class – against the intended application. For inverter operation, check separately whether the winding insulation and bearings are rated for it, since the register contains no data on this.
Technical data
Engine
| Rated output | 4 kWcorrect |
|---|
Dimensions and weights
| Weight | 31 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 100 L (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B5/B3correct |
| Efficiency at full load | 85 %correct |
| Efficiency at 75 % load | 85 %correct |
| Efficiency at half load | 84 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2000 (Legacy)correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Trojan MD1A100L2-2 have?
The Trojan MD1A100L2-2 delivers 4 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
