Toyota 8FGU20

Series: Toyota Forklift

Source: http://www.toyota.com.cn/mobile/about/museum/toyota_museum/a

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Toyota Forklift series from Toyota includes the 8FGU20. The engine has 4 cylinders, with a displacement of 2,228.6 cm³. The engine comes from TOYOTA. Rated speed is 2,570 rpm. The unladen weight is 3,210 kg. The wheelbase measures 1,652 mm. Ground clearance is 95.2 mm. Top speed is 17.5 km/h. The tank holds 60.2 litres. The fuel is petrol. Maximum torque is reached at 2,100 rpm. The engine fitted is the 4Y - ECS. The Toyota Forklift series covers 82 models. Unladen weight within it ranges from 1,111.3 to 37,653 kg; the 8FGU20 sits at the bottom of that range with 3,210 kg. Its immediate neighbours are the 8FBCU25 below it with 3,157 kg and the 8FGCU20 above it with 3,240 kg. 2440 Toyota models across 33 series are on record. The model is listed under Forklift trucks. 14 verified figures from 1 source are on file.

Technical data

Engine

Engine makeTOYOTAcorrect
Engine model4Y - ECScorrect
Fuelpetrolcorrect
Rated speed2,570 rpmcorrect
Speed at max. torque2,100 rpmcorrect
Cylinders4correct
Displacement2,228.6 cm³correct

Dimensions and weights

Width1,152.1correct
Wheelbase1,652correct
Ground clearance95.2correct
Unladen weight3,210 kgcorrect

Drivetrain and chassis

Tyre typepneumatic tyrescorrect
Top speed17.5 km/hcorrect
Turning radius2,150 mmcorrect

Working data

Lifting capacity1,800 kgcorrect
Lift height3,340 mmcorrect
Fuel tank capacity60.2 lcorrect

Other data

Lift speed36 m/mincorrect
Load centre600.2 mmcorrect

More machines with this engine (TOYOTA 4Y-ECS, 10)

Frequently asked questions

How much does the Toyota 8FGU20 weigh?

The unladen weight is 3,210 kg.

What engine does the Toyota 8FGU20 have?

4 cylinders, 2,229 cm³ displacement, Gasoline.

How fast does the Toyota 8FGU20 go?

Top speed is 17.5 km/h.

What is the load capacity of the Toyota 8FGU20?

Load capacity is 1,800 kg at a 600 mm load centre, lift height 3,340 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
