Toshiba CD200L2-6

Series: Other models

Source: https://toshiba.com/tic/spotlight/toshiba-introduces-the-eqp

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Toshiba CD200L2-6 is a three-phase induction motor. The rated output is 22 kW. The motor is six-pole, which at 50 Hz gives a synchronous speed of 1,000 rpm. The housing is frame size 200 L in foot-mounted form. The protection class is IP55. The efficiency is 91 per cent at full load, 91.3 per cent at 75 per cent load and 90.5 per cent at half load. The motor is built in Germany. The data is based on the Australian MEPS registration under standard AS/NZS 1359.5:2004; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Toshiba range ranges from 0.73 to 160 kW; the CD200L2-6 sits at the bottom of that range with 22 kW. Its immediate neighbours are the TKKH FCKW8 below it with 18.5 kW and the CD200L-4 above it with 30 kW. 105 Toshiba models are on record. The model is listed under Electric motors. 21 verified figures from 1 source are on file.

Technical data

Engine

Rated output22 kWcorrect

Electrical data

Number of poles6correct
Protection classIP55correct
Frame size200 L (foot)correct
Mounting (IEC 60034-7)B3, B5, B6, B7, B8, B14, B34, B35, V1, V3, V5, V6, V15, V18, V19, V36correct
Efficiency at full load91 %correct
Efficiency at 75 % load91.3 %correct
Efficiency at half load90.5 %correct

Origin and approval

Country of manufactureGermanycorrect
Standard appliedAS/NZS 1359.5:2004correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the Toshiba CD200L2-6 have?

The Toshiba CD200L2-6 delivers 22 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 21 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
