Toshiba 8YH-B0150

Series: Other models

The photo shows the 818-B1320 DIP from the same series. Source: https://www.weg.net/catalog/weg/RS/es/W21-Multimontaje/Multi

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Toshiba International 8YH-B0150 is a three-phase induction motor built by Toshiba International. The rated output is 15 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The housing is frame size 160 L in foot-mounted form. The efficiency is 92.3 per cent at full load, 92.8 per cent at 75 per cent load and 92.4 per cent at half load. Stated countries of manufacture: Taiwan and China. The figures come from the Australian MEPS register under the GEMS Determination 2019; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Toshiba International range ranges from 0.75 to 180 kW; the 8YH-B0150 sits at the bottom of that range with 15 kW. Its immediate neighbours are the ZWE 160L6 below it with 14 kW and the *2Y*-A0180 above it with 18.5 kW. 955 Toshiba International models are on record. The model is listed under Electric motors. 23 verified figures from 1 source are on file.

Technical data

Engine

Engine family8Y*-B0150correct
Engine families8Y*-B0150correct
Rated output15 kWcorrect

Electrical data

Number of poles4correct
Protection classIP00, IP01, IP02, IP10, IP11, IP12, IP13, IP14, IP15, IP20, IP21, IP22, IP23, IP24, IP25, IP30, IP31, IP32, IP33, IP34, IP35, IP40, IP41, IP42, IP43, IP44, IP45, IP46, IP47, IP48, IP50, IP51, IP52, IP53, IP54, IP55, IP56, IP57, IP58, IP65, IP66correct
Frame size160 L (foot)correct
Mounting (IEC 60034-7)B3, B5, B6, B7, B8, B9, B10, B14, B15, B20, B25, B30, B34, B35, V1, V2, V3, V4, V5, V6, V8, V9, V10, V14, V15, V16, V18, V19, V30, V31, V36correct
Efficiency at full load92.33 %correct
Efficiency at 75 % load92.78 %correct
Efficiency at half load92.37 %correct

Origin and approval

Country of manufactureTaiwan, Chinacorrect
Standard appliedGreenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the Toshiba 8YH-B0150 have?

The Toshiba 8YH-B0150 delivers 15 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
