Terex TS14G

Series: Terex Motor Scraper

Source: https://www.truck1.eu/construction-machinery/terex/damaged/f

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the TS14G, Terex offers a model from the Terex Motor Scraper series. The engine delivers 169.3 hp (117.8 kW), with a displacement of 5,899.3 cm³. Rated speed is 2,200 rpm. The wheelbase measures 7,001.3 mm. The tank holds 681.4 litres. The gearbox has 7 forward gears. There are also 1 reverse gears. The hydraulic tank holds 204.4 litres. The cooling system holds 85.2 litres. The electrical system runs on 24 V. Tyre size: 29,5 R 25 Radial 25". Rated output across the Terex range ranges from 18.2 to 4,562.4 hp; the TS14G sits at the bottom of that range with 169.3 hp. Its immediate neighbours are the CR362S below it with 167.3 hp and the AC200 above it with 172.4 hp. 377 Terex models across 29 series are on record. The model is listed under Mining equipment. 17 verified figures from 1 source are on file.

Technical data

Engine

Power	169.3 hp (117.8 kW)correct
Rated speed	2,200 rpmcorrect
Displacement	5,899.3 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	85.2 lcorrect

Dimensions and weights

Length	12,402.3correct
Width	3,401.6correct
Wheelbase	7,001.3correct

Drivetrain and chassis

Gearbox type	Funk DF158 powershift transmission, counter-shaft type Transmission with integral torque convcorrect
Forward gears	7correct
Reverse gears	1correct
Tyre size	29.5 R 25 Radial 25"correct
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	204.4 lcorrect
Fuel tank capacity	681.4 lcorrect

Other data

Height	3,301correct

Frequently asked questions

How much power does the Terex TS14G have?

The Terex TS14G delivers 169 hp.

What engine does the Terex TS14G have?

5,899 cm³ displacement.

What are the dimensions of the Terex TS14G?

12,402 mm × 3,402 mm.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
