Terex 1604MK

Series: Terex Mobile Excavator

Source: https://www.kleinanzeigen.de/s-anzeige/terex-minibagger-bagg

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex Mobile Excavator series from Terex includes the 1604MK. The engine delivers 133.3 hp (93.1 kW), with a displacement of 3,192.2 cm³. Rated speed is 2,300 rpm. The wheelbase measures 2,551.2 mm. Ground clearance is 350.5 mm. The tank holds 230.2 litres. The pump delivers 300.2 l/min. The hydraulic tank holds 300.2 litres. Working pressure is 340 bar. The oil fill is 10.2 litres. The engine fitted is the BF4M 2012 C. Tyre size: 10,00-20. The Terex Mobile Excavator series covers 10 models. Rated output within it ranges from 100.4 to 149.6 hp; the 1604MK sits in the upper part of that range with 133.3 hp. Its immediate neighbours are the 1305M below it with 103.4 hp and the 1605M above it with 149.6 hp. 377 Terex models across 29 series are on record. The model is listed under Excavators & compaction. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine modelBF4M 2012 Ccorrect
Power133.3 hp (93.1 kW)correct
Rated speed2,300 rpmcorrect
Displacement3,192.2 cm³correct
AspirationTurboladercorrect
Engine oil capacity10.2 lcorrect

Dimensions and weights

Wheelbase2,551.2correct
Ground clearance350.5correct

Drivetrain and chassis

Gearbox typeplanetary gearcorrect
Tyre size10.00-20correct

Working data

Pump flow300.2 l/mincorrect
Hydraulic oil capacity300.2 lcorrect
Hydraulic pressure340 barcorrect
Fuel tank capacity230.2 lcorrect

Other data

Height3,020.6correct

Frequently asked questions

How much power does the Terex 1604MK have?

The Terex 1604MK delivers 133 hp.

What engine does the Terex 1604MK have?

3,192 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
