Techtop TCP 200L2-2
Series: TCP
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Techtop TCP – register of three-phase motors with five-way voltage 400/415/440/480/690 V: 27 versions, 11 to 132 kW, 2- to 6-pole, IP55, High Efficiency Level 2005, made in China
The TCP range at Techtop covers three-phase industrial motors in the medium to upper power range. The model designation follows the pattern TCP plus frame size and pole count, for example TCP 225M-6 for the six-pole version of frame size 225M or TCP 280M-2 for the two-pole 280M version.
Read on 3 more paragraphs
The register lists here 27 versions with 11 to 132 kW, two- to six-pole. Full-load efficiencies range from 91.3 to 95.9% and at 75% load from 91.8 to 95.9%; all 27 versions reach the High Efficiency Level 2005 classification. All motors are built for the voltage combination 400/415/440/480/690 V and carry protection rating IP55 with a uniform mounting code B3/B5/B35/V1. Manufacturing is in China, tested to the GEMS 2019 determinations with test method A.
With its wide voltage rating from 400 to 690 V and consistent High Efficiency classification, TCP targets export to countries with different low-voltage grids; in the 11 to 132 kW power range the range covers typical applications in pumps, fans, compressors and conveyors.
When buying used, what matters is bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, pole count and the full voltage rating of 400/415/440/480/690 V, which must be observed when reconnecting.
Sources: Kennwerte der Modelle Techtop TCP
Technical data
Engine
| Rated output | 37 kWcorrect |
|---|
Electrical data
| Rated voltage | 400/415/440/480/690 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 200L (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B35, V1correct |
| Efficiency at full load | 93.8 %correct |
| Efficiency at 75 % load | 94.2 %correct |
| Efficiency at half load | 93.8 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Techtop TCP 200L2-2 have?
The Techtop TCP 200L2-2 delivers 37 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
