Tadano 15010

Series: Tadano Crawler Crane

Source: https://www.tadano.com/benelux/en/news/sueur-takes-delivery-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Tadano Crawler Crane series from Tadano includes the 15010. The engine delivers 263.6 hp (193.9 kW), has 6 cylinders, with a displacement of 6,700.7 cm³. The engine comes from Cummins. Torque is 987 Nm. Rated speed is 2,200 rpm. The unladen weight is 62,241 kg. Ground clearance is 335.3 mm. Top speed is 2.9 km/h. The tank holds 397.5 litres. Maximum torque is reached at 1,500 rpm. The hydraulic tank holds 1,135.6 litres. The electrical system runs on 12 V. The engine fitted is the QSB 6,7. The Tadano Crawler Crane series covers 5 models. Rated output within it ranges from 175.4 to 263.8 hp; the 15010 sits at the top of that range with 263.6 hp. Its immediate neighbours are the 6010 below it with 175.4 hp and the 10010MX above it with 263.8 hp. 111 Tadano models across 5 series are on record. The model is listed under Cranes & access platforms. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine makeCumminscorrect
Engine modelQSB 6.7correct
Power263.6 hp (193.9 kW)correct
Rated speed2,200 rpmcorrect
Torque987correct
Speed at max. torque1,500 rpmcorrect
Cylinders6correct
Displacement6,700.7 cm³correct
AspirationWater cooledcorrect

Dimensions and weights

Ground clearance335.3correct
Unladen weight62,241 kgcorrect

Drivetrain and chassis

Top speed2.9 km/hcorrect
System voltage12 Vcorrect

Working data

Hydraulic oil capacity1,135.6 lcorrect
Fuel tank capacity397.5 lcorrect

Where this model stands

Power-to-weight ratio: 3.1 kW/t (194 kW / 62.2 t)

Stronger than 49% of the crawler cranes in the register — out of 56 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Tadano 15010 have?

The Tadano 15010 delivers 264 hp.

How much does the Tadano 15010 weigh?

The unladen weight is 62,241 kg.

What engine does the Tadano 15010 have?

6 cylinders, 6,701 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
