System Trailer TKS 24
Built: 2009-2011 · Series: TKS
More machines from model year 2009
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
System Trailer TKS – semi-trailers from Papenburg: unladen weight 6,940 to 10,170 kg, gross weight 30,000 to 42,000 kg, length up to 14,050 mm, uniform width 2,600 mm
System Trailer is a semi-trailer manufacturer based in Papenburg. The TKS range gathers the company's semi-trailers for European road haulage in the register; the type designations TKS 18, TKS 20, TKS 24 and TKS 27 rise in even steps, distinguishing different builds within the range.
Read on 3 more paragraphs
The register lists here 6 versions with unladen weights from 6,940 to 10,170 kg, gross weights from 30,000 to 42,000 kg, lengths from 9,460 to 14,050 mm and a uniform width of 2,600 mm.
With gross weights up to 42 tonnes and lengths reaching over 14 metres, the TKS range is among the heavy standard semi-trailers of European long-haul transport. The span of build lengths allows the trailer to be matched to different load carriers, from shorter swap bodies to long standard semi-trailers, of the kind needed on scheduled routes between haulage depots and distribution centres.
When buying used, check the condition of the chassis and side rails, the axles, braking system and air suspension, and the function of the landing legs and kingpin. On the long versions it is also worth checking the chassis for sag and corrosion on the cross members, which see the heaviest wear at high mileage; the condition of the lighting system and tyres further indicates how well the trailer has been maintained and operated over time.
Technical data
Dimensions and weights
| Length | 14,050 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Wheelbase | 8,800 mmcorrect |
| Unladen weight | 9,080 kgcorrect |
| Gross vehicle weight | 39,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the System Trailer TKS 24 weigh?
The unladen weight is 9,080 kg.
What is the gross vehicle weight of the System Trailer TKS 24?
39,000 kg.
Up to what speed is the System Trailer TKS 24 approved?
Approved up to 100 km/h.
What are the dimensions of the System Trailer TKS 24?
14,050 mm × 2,600 mm.
When was the System Trailer TKS 24 built?
Production years: 2009-2011.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
