Sunward SWL3210

Series: Sunward Skid Steer Loader

Source: https://sunward.eu/sunward-mania/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Sunward SWL3210 is a model in the Sunward Skid Steer Loader series. The engine delivers 55 kW, has 4 cylinders. Rated speed is 2,600 rpm. The wheelbase measures 1,118.6 mm. Ground clearance is 205.2 mm. Top speed is 12.7 km/h. The tank holds 85.2 litres. The pump delivers 124.9 l/min. The hydraulic tank holds 65.1 litres. Working pressure is 250 bar. The cooling system holds 8.7 litres. The engine fitted is the V3300DI. Tyre size: 12-16,5. Rated output across the Sunward range ranges from 40 to 184 kW; the SWL3210 sits at the bottom of that range with 55 kW. Its immediate neighbours are the SWL2810 below it with 40 kW and the SWTL4518 above it with 74 kW. 8 Sunward models across 5 series are on record. The model is listed under Wheel loaders. 14 verified figures from 1 source are on file.

Technical data

Engine

Engine model	V3300DIcorrect
Power	55 kWcorrect
Rated speed	2,600 rpmcorrect
Cylinders	4correct
Coolant capacity	8.7 lcorrect

Dimensions and weights

Wheelbase	1,118.6correct
Ground clearance	205.2correct

Drivetrain and chassis

Tyre size	12-16.5correct
Top speed	12.7 km/hcorrect

Working data

Pump flow	124.9 l/mincorrect
Hydraulic oil capacity	65.1 lcorrect
Hydraulic pressure	250correct
Fuel tank capacity	85.2 lcorrect

Other data

Cab height	2,100.1correct

More machines with this engine (V3300DI, 2)

Frequently asked questions

How much power does the Sunward SWL3210 have?

The Sunward SWL3210 delivers 55 kW.

What engine does the Sunward SWL3210 have?

4 cylinders.

How fast does the Sunward SWL3210 go?

Top speed is 12.7 km/h.
