Simpson TSJ436E
Built: 2012-2012 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Technical data
Engine
| Engine family | CSCLL03.6V74correct |
|---|---|
| Engine families | CSCLL03.6V74correct |
| Fuel | 300-500 ppm Low Sulfur Diesel; 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 55 kWcorrect |
| Power band | 37<=kW<56correct |
| Rated speed | 2,200 rpmcorrect |
| Maximum torque | 294 N·mcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 4correct |
| Cylinder layout | in linecorrect |
| Bore | 95 mmcorrect |
| Stroke | 127 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | Fixed Turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Interim Tier 4correct |
Origin and approval
| Built from | 2012correct |
|---|---|
| Built to | 2012correct |
| Model year from | 2012correct |
| Model year to | 2012correct |
Frequently asked questions
How much power does the Simpson TSJ436E have?
The Simpson TSJ436E delivers 55 kW.
When was the Simpson TSJ436E built?
Production years: 2012.
