Siemens 1LG6 316–2AB60

Series: 1LG6

Source: https://press.siemens.com/at/de/pressemitteilung/siemens-ste

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Siemens 1LG6 316–2AB60 is a three-phase induction motor. The rated output is 160 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The rated voltage is 415 V. The housing is frame size 315 L in foot-mounted form. The protection class is IP55. The efficiency is 96.4 per cent at full load, 96.4 per cent at 75 per cent load and 95 per cent at half load. The motor weighs 1,055 kg. At full load it delivers 512 Nm. Stated countries of manufacture: Czechia and Germany. The figures come from the Australian MEPS register under standard AS/NZS 1359.5:2004; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Siemens range ranges from 0.75 to 200 kW; the 1LG6 316–2AB60 sits in the upper part of that range with 160 kW. Its immediate neighbours are the 1PC3004-3AA44-7JB0 below it with 145 kW and the 1LG6 317–2AB.. above it with 200 kW. 570 Siemens models across 2 series are on record. The model is listed under Electric motors. 23 verified figures from 1 source are on file.

Technical data

Engine

Rated output160 kWcorrect

Dimensions and weights

Weight1,055 kgcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles2correct
Protection classIP55correct
Frame size315 L (foot)correct
Mounting (IEC 60034-7)MB3, IMB5correct
Efficiency at full load96.4 %correct
Efficiency at 75 % load96.4 %correct
Efficiency at half load95 %correct

Origin and approval

Country of manufactureCzechia, Germanycorrect
Standard appliedAS/NZS 1359.5:2004correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the Siemens 1LG6 316–2AB60 have?

The Siemens 1LG6 316–2AB60 delivers 160 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
