Scania 730 CB10X4*6HSZ

Built: 2014-2014 · Series: R

The photo shows the 114 GB 8X2*6 NA 340 from the same series. Source: https://www.kleinanzeigen.de/s-anzeige/scania-r340-lkw-satte

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 730 CB10X4*6HSZ from Scania is part of the R series. Production: 2014. The engine delivers 537 kW, has 8 cylinders, with a displacement of 16,353 cm³. The machine is 10,106 mm long and 2,550 mm wide. The unladen weight is 18,750 kg. The gross vehicle weight is 52,500 kg. The R series covers 1740 models. Rated output within it ranges from 207 to 566 kW; the 730 CB10X4*6HSZ sits at the top of that range with 537 kW. Its immediate neighbours are the 660XT below it with 485 kW and the 770 A6x2/4LB above it with 566 kW. 7586 Scania models across 18 series are on record. The model is listed under Trucks over 7.5 t. 8 verified figures from 1 source are on file.

Scania R — the letter is the cab, not the engine

Scania's R says nothing about engine or weight. It names the cab. Scania grades its cabs by height and entry: P is the low one, G the medium, R the tall long-haul cab, S the tallest with a flat floor and no engine tunnel. Anyone looking for an R is therefore looking first for a place to live in — long haul, overnight stays, standing room.

Read on 4 more paragraphs

The number after it is engine output in horsepower. An R 450 has 450 hp, an R 500 has 500. Read together, the designation is cab plus power — unlike MAN or Mercedes, where the first number means gross vehicle weight. Anyone comparing offers across brands should know this difference, or they will be comparing weight against power.

A suffix such as A4x2NA or B6x4HZ often follows. The first letter gives the body type (A = tractor unit, B = platform chassis), the digits the axle configuration, the final letters the suspension — N for air, H for leaf springs on the rear axle. That suffix often says more about a used vehicle's suitability than the horsepower figure does.

Important when searching: two vehicle generations share the letter. The R-series of 2004 was followed in 2016 by the next generation, developed internally as the New Truck Generation. Both are simply called R in listings. Two vehicles with identical designations can therefore be twelve years of development apart — what decides is first registration and emissions standard, not the letter.

Further back, Scania trucks carried plain numbers: 113, 143, 164. There the first digit stood for displacement in litres and the last for the series, so 113 meant eleven litres from the 3-series. That reading no longer applies to the R — but it explains why both systems appear side by side in used listings.

Sources: Scania Group, Wikipedia: Scania 3-series, Fleet News

Technical data

Engine

Power537 kWcorrect
Cylinders8correct
Displacement16,353 cm³correct

Dimensions and weights

Length10,106 mmcorrect
Width2,550 mmcorrect
Unladen weight18,750 kgcorrect
Gross vehicle weight52,500 kgcorrect

Where this model stands

Power-to-weight ratio: 28.6 kW/t (537 kW / 18.8 t)

Stronger than 99% of the trucks over 7.5 t in the register — out of 27,962 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Scania 730 CB10X4*6HSZ have?

The Scania 730 CB10X4*6HSZ delivers 537 kW.

How much does the Scania 730 CB10X4*6HSZ weigh?

The unladen weight is 18,750 kg.

What is the gross vehicle weight of the Scania 730 CB10X4*6HSZ?

52,500 kg.

What engine does the Scania 730 CB10X4*6HSZ have?

8 cylinders, 16,353 cm³ displacement.

What are the dimensions of the Scania 730 CB10X4*6HSZ?

10,106 mm × 2,550 mm.

When was the Scania 730 CB10X4*6HSZ built?

Production years: 2014.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
