Scania 470 B6X2

Built: 2006-2006 · Series: R

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The R series from Scania includes the 470 B6X2. Production: 2006. The engine has 6 cylinders, with a displacement of 11,705 cm³. The machine is 9,150 mm long and 2,550 mm wide. The unladen weight is 11,830 kg. The wheelbase measures 6,200 mm. The gross vehicle weight is 25,700 kg. The machine runs on 6 wheels. The R series covers 1740 models. Unladen weight within it ranges from 6,580 to 76,711 kg; the 470 B6X2 sits at the bottom of that range with 11,830 kg. Its immediate neighbours are the 143 HL-6X2/460+132 below it with 11,825 kg and the 380 LB 6X4 HNA above it with 11,837 kg. 7586 Scania models across 18 series are on record. The model is listed under Trucks over 7.5 t. 10 verified figures from 1 source are on file.

Scania R — the letter is the cab, not the engine

Scania's R says nothing about engine or weight. It names the cab. Scania grades its cabs by height and entry: P is the low one, G the medium, R the tall long-haul cab, S the tallest with a flat floor and no engine tunnel. Anyone looking for an R is therefore looking first for a place to live in — long haul, overnight stays, standing room.

Read on 4 more paragraphs

The number after it is engine output in horsepower. An R 450 has 450 hp, an R 500 has 500. Read together, the designation is cab plus power — unlike MAN or Mercedes, where the first number means gross vehicle weight. Anyone comparing offers across brands should know this difference, or they will be comparing weight against power.

A suffix such as A4x2NA or B6x4HZ often follows. The first letter gives the body type (A = tractor unit, B = platform chassis), the digits the axle configuration, the final letters the suspension — N for air, H for leaf springs on the rear axle. That suffix often says more about a used vehicle's suitability than the horsepower figure does.

Important when searching: two vehicle generations share the letter. The R-series of 2004 was followed in 2016 by the next generation, developed internally as the New Truck Generation. Both are simply called R in listings. Two vehicles with identical designations can therefore be twelve years of development apart — what decides is first registration and emissions standard, not the letter.

Further back, Scania trucks carried plain numbers: 113, 143, 164. There the first digit stood for displacement in litres and the last for the series, so 113 meant eleven litres from the 3-series. That reading no longer applies to the R — but it explains why both systems appear side by side in used listings.

Sources: Scania Group, Wikipedia: Scania 3-series, Fleet News

Technical data

Engine

Cylinders6correct
Displacement11,705 cm³correct

Dimensions and weights

Length9,150 mmcorrect
Width2,550 mmcorrect
Wheelbase6,200 mmcorrect
Unladen weight11,830 kgcorrect
Gross vehicle weight25,700 kgcorrect

Drivetrain and chassis

Wheels6correct

Frequently asked questions

How much does the Scania 470 B6X2 weigh?

The unladen weight is 11,830 kg.

What is the gross vehicle weight of the Scania 470 B6X2?

25,700 kg.

What engine does the Scania 470 B6X2 have?

6 cylinders, 11,705 cm³ displacement.

What are the dimensions of the Scania 470 B6X2?

9,150 mm × 2,550 mm.

When was the Scania 470 B6X2 built?

Production years: 2006.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
