Scania DC16 084A
Built: 2014-2018 · Series: DC16
More machines from model year 2014
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Scania DC16 — the V8 Heavy Diesel for Industry, Marine and Standby Power
The Scania DC16 is a 90-degree V8 diesel engine with 16.4 litres of displacement (130 x 154 mm bore and stroke, 16.7:1 compression ratio), built for Scania's heavy industrial and marine range. Fuel is delivered by Scania's XPI extra-high-pressure common-rail system under the control of the manufacturer's own Engine Management System (EMS); the strength-optimised block with wet liners and individual four-valve cylinder heads is designed for serviceability.
Read on 3 more paragraphs
Across the various factory-rated versions, output ranges from around 368 kW up to more than 680 kW (up to roughly 770 kVA in standby-power form) — placing the DC16 above the smaller 9-litre five-cylinder DC09 as the top of Scania's industrial engine range. No reliable production period or specific predecessor is documented for this entry.
Applications include heavy off-road and industrial machinery, marine main propulsion, and large prime/standby generator sets; variants held in the records include DC16 070A, 083A, 084A, 085A and 091A.
As with other Scania industrial engines, the most useful check on a used unit is the maintenance record for oil changes and fuel filtration (including the pre-filter/water separator and fuel heater), plus the condition of the centrifugal oil cleaner; no specific, externally documented weak points are reported beyond that.
Sources: Kennwerte der Modelle DC16, – Scania DC16 086A Datenblatt (566 kW), – Scania DC16 078A Power-Gen-Datenblatt, – DirectIndustry Produktseite DC16 078A
Technical data
Engine
| Engine code | 2 257 384correct |
|---|---|
| Engine family | EY9XL16.4DAA; GY9XL16.4DAA; FY9XL16.4DAA; HY9XL16.4DAAcorrect |
| Engine families | EY9XL16.4DAA; GY9XL16.4DAA; FY9XL16.4DAA; HY9XL16.4DAAcorrect |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 405 kWcorrect |
| Power band | 130<=kW<=560correct |
| Rated speed | 2,100 rpmcorrect |
| Maximum torque | 2,828 N·mcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 8correct |
| Cylinder layout | V layoutcorrect |
| Bore | 130 mmcorrect |
| Stroke | 154 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | Variable Geometry Turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Version | 2 257 384correct |
|---|---|
| Built from | 2014correct |
| Built to | 2017correct |
| Model year from | 2014correct |
| Model year to | 2025correct |
Frequently asked questions
How much power does the Scania DC16 084A have?
The Scania DC16 084A delivers 405 kW.
When was the Scania DC16 084A built?
Production years: 2014-2018.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 26 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
