Samt YSS-80M2-4
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Samt – other models: the collective page of three-phase motors from the Australian GEMS/MEPS register, 0.75 to 90 kW, 2- to 6-pole, Chinese-Romanian manufacture, efficiencies up to 95.5%
This page gathers the three-phase motors registered under the Samt brand in the Australian GEMS/MEPS register that could not be assigned to a named range. Samt's headquarters and group ownership cannot be reliably determined from the register; what is confirmed is the origin of manufacture: the majority of the 120 models come from China, a smaller share from Romania, and a single model from Rwanda. The type codes follow the pattern E2-ASA-frame size-pole count, for example E2-ASA-100La-2; the leading E2 is likely to indicate an efficiency class, ASA presumably an enclosure or material variant, though this cannot be reliably confirmed from the register.
Read on 3 more paragraphs
The register lists here 120 versions from 0.75 to 90 kW, 2- to 6-pole, with efficiencies from 79 to 95.5% at full load and 77.7 to 95.8% at 75% load, protection classes IP55 and IP66, and frame sizes from 80 to 280 (IEC). For 53 of the models the classification "2005 High Efficiency Level" is recorded; the rest carry no GEMS efficiency classification.
With an upper power limit of 90 kW and frame sizes up to 280, Samt covers a smaller and lighter drive spectrum in the register than most of the other brands gathered here; manufacture in China and Romania suggests a Europe-oriented distribution line alongside the Chinese core production.
For used Samt motors, the usual checkpoints for standard motors apply: measure the winding's insulation resistance, check the bearings for running noise and play, check the shaft turns freely, assess the condition of the fan and fan cowl, and match the rating plate – frame size, pole count, protection class and efficiency class – against the intended application. For inverter operation, check separately whether the winding insulation and bearings are rated for it, since the register contains no data on this.
Technical data
Engine
| Rated output | 0.75 kWcorrect |
|---|
Electrical data
| Rated voltage | 230/240/400/415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP66correct |
| Frame size | 80 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B14, B34, B35correct |
| Efficiency at full load | 82.5 %correct |
| Efficiency at 75 % load | 82 %correct |
| Efficiency at half load | 79.4 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Samt YSS-80M2-4 have?
The Samt YSS-80M2-4 delivers 0.8 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
