Sakai GW750

Series: Sakai Pneumatic Roller

Source: http://www.wirtgen-group.com/de-nl/news-und-media/wirtgen-gr

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Sakai GW750 belongs to the Sakai Pneumatic Roller series. The engine delivers 104.7 hp (77 kW), with a displacement of 4,329.5 cm³. Rated speed is 1,600 rpm. The wheelbase measures 3,002.3 mm. Ground clearance is 286.5 mm. Top speed is 9 km/h. The tank holds 130.2 litres. The hydraulic tank holds 65.1 litres. The engine fitted is the "DD-4BG1T" Diesel engine. The Sakai Pneumatic Roller series covers 5 models. Rated output within it ranges from 19.9 to 104.7 hp; the GW750 sits at the top of that range with 104.7 hp. Its immediate neighbours are the T2-1 below it with 99.3 hp. 50 Sakai models across 5 series are on record. The model is listed under Road construction. 12 verified figures from 1 source are on file.

Technical data

Engine

Engine model"DD-4BG1T" Diesel enginecorrect
Power104.7 hp (77 kW)correct
Rated speed1,600 rpmcorrect
Displacement4,329.5 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Width2,200.7correct
Wheelbase3,002.3correct
Ground clearance286.5correct

Drivetrain and chassis

Top speed9 km/hcorrect

Working data

Hydraulic oil capacity65.1 lcorrect
Fuel tank capacity130.2 lcorrect

Frequently asked questions

How much power does the Sakai GW750 have?

The Sakai GW750 delivers 105 hp.

What engine does the Sakai GW750 have?

4,330 cm³ displacement.

How fast does the Sakai GW750 go?

Top speed is 9 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
