Saacke YA90L-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Saacke – other models: the collective page of MEPS-registered three-phase motors from the Bremen burner-technology maker outside the named ranges, frame sizes 90 to 160, 2.2 to 11 kW, two-pole, IP55
Saacke is a manufacturer of burner technology headquartered in Bremen. This page gathers three-phase motors carrying the brand that the Australian energy-efficiency register (GEMS/MEPS) does not assign to a named range. The four versions carry the designations YA90L-2, YA100L-2, YA132Sb-2 and YA160Ma-2.
Read on 3 more paragraphs
The register lists here four versions with 2.2 to 11 kW rated output, all two-pole and rated for 415 V. Full-load efficiency ranges from 84.1 to 89.5%, and at 75% load from 85.3 to 89.2%. Frame sizes fall between 90 and 160, the protection class is IP55 throughout, and the mounting code is B5 throughout. Testing followed AS/NZS 1359.5:2004 with test method A.
As high-speed two-pole motors, the four versions suit drives matched to burner and combustion plant, for instance fan and pump drives on oil or gas burners; IP55 protection allows operation in boiler houses and heating plant rooms exposed to dust and moisture, without a need for a separate protective enclosure.
On a used purchase, bearing condition, a tested winding insulation resistance, visible overheating traces at the terminal box and fan cover, and a legible nameplate with frame size, pole count and protection class all count. Anyone wanting variable-speed operation should check inverter compatibility. Spare parts run through the Saacke service network or general electric-motor suppliers.
Sources: Kennwerte der Modelle Saacke (weitere Elektromotoren, MEPS-Registrierung), Saacke (Hersteller)
Technical data
Engine
| Rated output | 2.2 kWcorrect |
|---|
Dimensions and weights
| Weight | 16.8 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 90 L (foot)correct |
| Mounting (IEC 60034-7) | B5correct |
| Efficiency at full load | 84.1 %correct |
| Efficiency at 75 % load | 85.3 %correct |
| Efficiency at half load | 83.7 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2004correct |
|---|---|
| Test method | IEEE 112-B(USA)correct |
Frequently asked questions
How much power does the Saacke YA90L-2 have?
The Saacke YA90L-2 delivers 2.2 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
