Rotek RXA 15Kw 3 Phase 4 Pole Motor

Series: RXA

The photo shows the RXA 11Kw 3 Phase 4 Pole Motor from the same series. Source: https://www.weg.net/catalog/weg/CI/en/Electric-Motors/Low-Vo

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Rotek RXA 15Kw 3 Phase 4 Pole Motor is a three-phase induction motor built by Rotek. The rated output is 15 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 400 V. The housing is frame size 160 L in foot-mounted form. The protection class is IP55. The efficiency is 91 per cent at full load, 90.7 per cent at 75 per cent load and 89.7 per cent at half load. The mounting arrangement to IEC 60034-7 is B3. The motor is built in Taiwan. The figures come from the Australian MEPS register under standard AS/NZS 1359.5:2004; measured to AS/NZS 1359.102.3:2000. Rated output across the Rotek range ranges from 0.18 to 160 kW; the RXA 15Kw 3 Phase 4 Pole Motor sits at the bottom of that range with 15 kW. Its immediate neighbours are the RXQ 11Kw 3 Phase Vertical 2 Pole Motor below it with 11 kW and the 160L-2 above it with 18.5 kW. 132 Rotek models are on record. The model is listed under Electric motors. 22 verified figures from 1 source are on file.

Technical data

Engine

Rated output15 kWcorrect

Electrical data

Rated voltage400 Vcorrect
Number of poles4correct
Protection classIP55correct
Frame size160 L (foot)correct
Mounting (IEC 60034-7)B3correct
Efficiency at full load91.01 %correct
Efficiency at 75 % load90.65 %correct
Efficiency at half load89.68 %correct

Origin and approval

Country of manufactureTaiwancorrect
Standard appliedAS/NZS 1359.5:2004correct
Test methodAS/NZS 1359.102.3:2000correct

Frequently asked questions

How much power does the Rotek RXA 15Kw 3 Phase 4 Pole Motor have?

The Rotek RXA 15Kw 3 Phase 4 Pole Motor delivers 15 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
