Rolfo S2330 RF
Built: 1998-1998 · Series: Other models
More machines from model year 1998
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Rolfo – other models: the collective page of Italian car-transporter trailers outside the named ranges, ranges such as Centaurus, Arctic and Sirio, 13.4 to 38 tonnes gross weight, up to 17.28 metres in length
This page gathers the Rolfo trailers the register could not assign to a named range. Rolfo is an Italian builder of car transporters with ranges such as Centaurus, Arctic and Sirio and technical types such as S2330RF or SA2210TV, whose codes indicate axle count and equipment such as hydraulic ramps or tilting axles.
Read on 3 more paragraphs
The register lists here 30 versions with unladen weights from 3,650 to 14,300 kg, gross weights from 13,400 to 38,000 kg, lengths from 10,150 to 17,280 mm and widths from 2,500 to 2,600 mm.
Car transporters of this type carry several vehicles at once between factory, dealer and scrapyard and are fitted with hydraulically adjustable, in part two-tier loading decks and extendable frames for different vehicle lengths; Rolfo ranks alongside Lohr and Kässbohrer among the established European suppliers of this segment. Equipment often includes liftable axles that are raised when empty or partly loaded, to reduce tyre wear and toll costs.
On used car transporters, the function and tightness of the hydraulics for ramps and decks, the condition of winches and lashing straps, frame and axles, and wear on the run-up rails all count; parts and service run through specialist vehicle-transporter workshops. The condition of the decks is also worth assessing for marks left by lashing chains, which can point to careless previous use.
Sources: Kennwerte der Modelle Rolfo (weitere Modelle), Rolfo (Hersteller)
Technical data
Dimensions and weights
| Length | 13,060 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Wheelbase | 8,100 mmcorrect |
| Unladen weight | 7,120 kgcorrect |
| Gross vehicle weight | 29,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Rolfo S2330 RF weigh?
The unladen weight is 7,120 kg.
What is the gross vehicle weight of the Rolfo S2330 RF?
29,000 kg.
Up to what speed is the Rolfo S2330 RF approved?
Approved up to 100 km/h.
What are the dimensions of the Rolfo S2330 RF?
13,060 mm × 2,600 mm.
When was the Rolfo S2330 RF built?
Production years: 1998.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
