Raf RA 20000
Built: 2008-2008 · Series: RA
More machines from model year 2008
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Raf RA: the trailer range with around 20 to 30 t gross vehicle weight, 1.68 to 7.05 t unladen weight and 8.55 to 12 m length, in versions such as K, KD, KDT, AS, SD and PD
Raf RA denotes a range of trailers whose model list gives a numbered base series from RA 20 to RA 30 plus numerous versions such as K, KD, KDT, AS, YD, SD and PD; the spelling in the list alternates between RA and the long form R.A., but consistently denotes the same range.
Read on 3 more paragraphs
The register lists 32 versions here with unladen weights from 1,680 to 7,050 kg at gross vehicle weights of 20,000 to 30,000 kg. Lengths run from 8,550 to 12,020 mm, widths from 2,460 to 2,600 mm.
With a gross weight between 20 and 30 t, the RA range sits among classic tandem and tridem-axle trailers for commercial vehicle use and competes with other European builders of similar trailer classes; the relatively narrow length range of 8.55 to 12 m shows that the range rests on a uniform base design with variable equipment.
When buying used, this range calls for checking the condition of the frame and axle mounts, corrosion on load-bearing parts, the function of the brake system and overrun coupling, and tyre and wheel bearing wear; on the various K and D versions it is also worth comparing the equipment actually fitted against the registration documents. Spare parts come through workshops specialising in this trailer class; on older examples the frame is also worth checking for cracks around the axle mounts.
Sources: Kennwerte der Modelle Raf RA
Technical data
Dimensions and weights
| Length | 8,550 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 5,190 mmcorrect |
| Unladen weight | 4,140 kgcorrect |
| Gross vehicle weight | 20,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Raf RA 20000 weigh?
The unladen weight is 4,140 kg.
What is the gross vehicle weight of the Raf RA 20000?
20,000 kg.
Up to what speed is the Raf RA 20000 approved?
Approved up to 100 km/h.
What are the dimensions of the Raf RA 20000?
8,550 mm × 2,550 mm.
When was the Raf RA 20000 built?
Production years: 2008.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
