Pacton SXD 228
Built: 2001-2001 · Series: SXD
More machines from model year 2001
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Pacton SXD – heavy semi-trailer range from the Dutch manufacturer: 10 versions, unladen weight from 5,120 to 12,490 kg, gross weight from 15,000 to 50,000 kg, lengths up to 14,030 mm
Pacton, based in Werkendam in the Netherlands, is one of the established European semi-trailer manufacturers; the SXD range covers a wide spectrum of versions in the register, from medium-heavy to particularly heavy semi-trailers. The type designation consists of the SXD prefix and a three- to four-digit number distinguishing individual models.
Read on 3 more paragraphs
The register lists here 10 versions with unladen weights from 5,120 to 12,490 kg and a gross weight from 15,000 to 50,000 kg. Lengths, where recorded, range from 12,730 to 14,030 mm, and widths from 2,550 to 2,600 mm.
With gross weights of up to 50 tonnes, the SXD range extends beyond the usual size of a standard semi-trailer, thereby also covering the lower end of the heavy-duty segment, for example for building materials, machinery or particularly dense loads. The spread of unladen weights from around 5 to 12.5 tonnes shows the varying construction within the range, from lighter to reinforced chassis versions.
When buying a used Pacton semi-trailer of this range, check above all the frame and side members around the axle suspension, the condition of the braking system and tyres, and, depending on version, the load floor, side boards or tarpaulin; on the heavier variants it is also worth checking for any deformation from overloading. Spare parts are available through the general semi-trailer parts trade and from Pacton directly.
Sources: Kennwerte der Modelle Pacton SXD, Pacton (Hersteller)
Technical data
Dimensions and weights
| Length | 14,030 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Wheelbase | 8,900 mmcorrect |
| Unladen weight | 12,490 kgcorrect |
| Gross vehicle weight | 28,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Pacton SXD 228 weigh?
The unladen weight is 12,490 kg.
What is the gross vehicle weight of the Pacton SXD 228?
28,000 kg.
Up to what speed is the Pacton SXD 228 approved?
Approved up to 100 km/h.
What are the dimensions of the Pacton SXD 228?
14,030 mm × 2,600 mm.
When was the Pacton SXD 228 built?
Production years: 2001.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
