New Holland B95TC

Series: New Holland Loader Backhoe

Source: https://www.agrarheute.com/technik/traktoren/new-holland-neu

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The New Holland B95TC is a model in the New Holland Loader Backhoe series. The engine delivers 96.6 hp (66.1 kW), has 4 cylinders, with a displacement of 4,501.5 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,176.3 mm. Ground clearance is 396.2 mm. The tank holds 135.1 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 151 l/min. The hydraulic tank holds 117.3 litres. Working pressure is 209.9 bar. The cooling system holds 24.2 litres. The electrical system runs on 12 V. The engine fitted is the 445T/M2. The New Holland Loader Backhoe series covers 25 models. Rated output within it ranges from 84.2 to 111.5 hp; the B95TC sits in the middle of that range with 96.6 hp. Its immediate neighbours are the LB75.B below it with 96.3 hp and the B90B above it with 98.3 hp. 502 New Holland models across 32 series are on record. The model is listed under Wheel loaders. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model445T/M2correct
Power96.6 hp (66.1 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement4,501.5 cm³correct
Aspirationturbochargedcorrect
Coolant capacity24.2 lcorrect

Dimensions and weights

Wheelbase2,176.3correct
Ground clearance396.2correct

Drivetrain and chassis

Gearbox typePower-Reversing/Torque Convcorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow151 l/mincorrect
Hydraulic oil capacity117.3 lcorrect
Hydraulic pressure209.9correct
Fuel tank capacity135.1 lcorrect

Frequently asked questions

How much power does the New Holland B95TC have?

The New Holland B95TC delivers 96.6 hp.

What engine does the New Holland B95TC have?

4 cylinders, 4,502 cm³ displacement.
