Nederman MSE3-90L-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Nederman – other electric motors: the collective page of drives for extraction and filter technology outside the named ranges, MSE3/MSHE, 1.1 to 18.5 kW, 230/400 and 400/690 V
This page gathers the Nederman electric motors the Australian energy-efficiency register (GEMS/MEPS) could not assign to a named range. Nederman is a Swedish company for air-quality and extraction technology headquartered in Helsingborg, making welding-fume extraction systems, industrial vacuum cleaners and filter plant; the motors registered here drive fans and suction units within this equipment. The MSE3 and MSHE type codes describe two different motor lines in the Nederman programme.
Read on 3 more paragraphs
The register lists here 9 versions with 1.1 to 18.5 kW, exclusively two-pole, at voltages of 230/400 V (7 motors) or 400/690 V (2 motors). Full-load efficiencies range from 84.24 to 93.33%, and at 75% load from 83.96 to 93.62%. Frame sizes run from 80 to 160, protection is mostly IP56, in part also approved for IP55. Manufacturing is exclusively in China, testing mostly followed the 2019 GEMS determination with test methods A (5) and B (4); three of the nine motors reach the 2005 High Efficiency Level, six remain unclassified.
The motors are bought-in components for Nederman's extraction and filter technology, with which the company clears workshops, welding shops and industrial halls of smoke, dust and fumes; as a drive they stay in the background of the actual plant products, but are decisive for their air performance.
When buying used, bearing condition and a checked insulation resistance of the winding, the condition of the terminal box and fan cover, a legible nameplate with frame size, voltage marking (230/400 or 400/690 V) and, where present, the High Efficiency Level marking matter; on the 400/690 V versions, the correct mains voltage should be checked before connecting. Spares run through Nederman service.
Sources: Kennwerte der Modelle Nederman (weitere Modelle, MEPS-Registrierungen), Nederman (Hersteller)
Technical data
Engine
| Rated output | 2.2 kWcorrect |
|---|
Dimensions and weights
| Weight | 19 kgcorrect |
|---|
Electrical data
| Rated voltage | 230/400 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55, IP56correct |
| Frame size | 90 L (foot)correct |
| Mounting (IEC 60034-7) | B3, B5correct |
| Efficiency at full load | 87.48 %correct |
| Efficiency at 75 % load | 87.76 %correct |
| Efficiency at half load | 86.34 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Nederman MSE3-90L-2 have?
The Nederman MSE3-90L-2 delivers 2.2 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
