Mustang 3803ZT
Series: Mustang Mini Excavator
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Mustang mini excavators ME1503 to ME3703 and 2803ZT to 3803ZT – the red Gehl twins: ME for Mustang Excavator, the number as weight class, ZT for zero tail, Yanmar three- and four-cylinders of 1.1 to 2.2 litres, 13 to 24 kW, 1.7 to 3.7 t
Mustang's mini excavators are the red twins of the Gehl mini excavators: since Gehl of West Bend took over the Mustang brand in 1997, skid steers and excavators were sold identically in yellow and red, and after Manitou bought both in 2008 that continued until Mustang was absorbed into the Manitou brand in 2020. The type logic: ME stands for Mustang Excavator, the number gives the weight class in hundreds of kilograms – ME1503 about 1.5 t, ME2203 2.2 t, ME3003 3 t, ME3703 3.7 t – the 03 at the end the series; the 2803ZT and 3803ZT are the zero-tail versions of the 2.8 and 3.8 tonne class that slew within the track width. The engines come from Yanmar – 3TNV76 of 1.1 litres in the small, 3TNV88 and 4TNV88 of 1.6 and 2.2 litres in the big models – to emission stage III.
Read on 3 more paragraphs
The register lists 7 versions with 13.4 to 23.9 kW from three- and four-cylinders of 1,114 to 2,189 cm³ and operating weights from 1,705 to 3,726 kg.
Mustang excavators were sold in North America through the Mustang dealer network and are rare in Europe; for buyers the twin layout means a Gehl or Manitou dealer knows the machine and carries parts.
On used machines, operating hours, play in boom, stick and offset-boom bearings, the condition of undercarriage and rubber tracks, leak-free cylinders and swivel joint and parts supply through Manitou and Yanmar count.
Sources: Kennwerte der Modelle Mustang Minibagger, Manitou Group (Rechtsnachfolger Mustang)
Technical data
Engine
| Engine model | 3TNV88-NNScorrect |
|---|---|
| Power | 36.9 hp (21.5 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 1,642 cm³correct |
Dimensions and weights
| Ground clearance | 280.4correct |
|---|---|
| Unladen weight | 3,629.6 kgcorrect |
Working data
| Pump flow | 118.1 l/mincorrect |
|---|---|
| Hydraulic pressure | 210 barcorrect |
Other data
| Cab height | 2,490.2correct |
|---|
Where this model stands
Power-to-weight ratio: 5.9 kW/t (22 kW / 3.6 t)
Stronger than 70% of the mini excavators in the register — out of 400 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Mustang 3803ZT have?
The Mustang 3803ZT delivers 36.9 hp.
How much does the Mustang 3803ZT weigh?
The unladen weight is 3,630 kg.
What engine does the Mustang 3803ZT have?
3 cylinders, 1,642 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 11 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
