Merlo P41.7
Built: 2014-2014 · Series: Other models
More machines from model year 2014
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Merlo P41.7 is a tractor built in 2014. Under the bonnet works a four-cylinder engine displacing 4 litres, producing 103 kW.
Dimensions are 4.33 m by 2.28 m. Empty, it weighs 8,625 kg.
Within the range, rated power spans from 54.6 to 125 kW; with 103 kW, the P41.7 sits in the upper third. Directly alongside are the TF38.10TTCS-140 with 100 kW below and the TF50.8TCS-156-CVTRONIC with 115 kW above.
Merlo – other models: collective page of Italian telehandlers outside the named ranges, Panoramic (P), Turbofarmer (TF) and Multifarmer (MF), 54.6 to 125 kW, 3.4 to 10 t lift capacity
This page gathers the Merlo machines the register could not assign to a named range – telehandlers throughout, rather than classic field tractors. Merlo is an Italian maker of telehandlers with the product families Panoramic (P, compact construction and yard loaders), Turbofarmer (TF, agricultural version) and Multifarmer (MF, with PTO and tow hitch, usable as a tractor too). The type numbers give lift capacity in tonnes and maximum lift height in metres, as with the P 40.7 for 4.0 t at 7 m or the TF 38.10 for 3.8 t at 10 m; the CVTRONIC suffix denotes the stepless transmission.
Read on 3 more paragraphs
The register lists here 24 versions with 54.6 to 125 kW from three- to six-cylinder engines of 3,331 to 4,500 cm³, unladen weights of 4,900 to 10,000 kg, gross weights of 6,400 to 12,500 kg, lengths of 4,230 to 5,250 mm and widths of 2,050 to 2,400 mm.
Merlo telehandlers are widespread in agriculture, construction and industry; the Multifarmer range in particular positions itself as an alternative to the classic yard tractor, since it combines loader work and PTO work in one machine.
When buying used, the condition of the telescopic boom and slide pads, tightness of the hydraulic cylinders, wear on the attachment plate and quick coupler, and on the CVTRONIC models the transmission electronics all matter. Parts and service run through the Merlo dealer network.
Sources: Kennwerte der Modelle Merlo (weitere Modelle), Merlo (Hersteller)
Technical data
Engine
| Power | 103 kWcorrect |
|---|---|
| Cylinders | 4correct |
| Displacement | 4,038 cm³correct |
Dimensions and weights
| Length | 4,330 mmcorrect |
|---|---|
| Width | 2,280 mmcorrect |
| Unladen weight | 8,625 kgcorrect |
| Gross vehicle weight | 10,000 kgcorrect |
Where this model stands
Power-to-weight ratio: 11.9 kW/t (103 kW / 8.6 t)
Power class: Large (100–180 hp)
Stronger than 81% of the tractors in the register — out of 15,659 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Merlo P41.7 have?
The Merlo P41.7 delivers 103 kW.
How much does the Merlo P41.7 weigh?
The unladen weight is 8,625 kg.
What is the gross vehicle weight of the Merlo P41.7?
10,000 kg.
What engine does the Merlo P41.7 have?
4 cylinders, 4,038 cm³ displacement.
What are the dimensions of the Merlo P41.7?
4,330 mm × 2,280 mm.
When was the Merlo P41.7 built?
Production years: 2014.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
