McCormick CN59
Built: 2010-2010 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The McCormick CN59 is a tractor built in 2010. 56 hp (41 kW) is what the four-cylinder engine gets out of 3.3 litres. With a rated speed of 2,500 rpm, it is built for pulling power, not for revving.
It runs with MFWD. At 28 km/h, that is as fast as it goes. Empty, it weighs 2,520 kg.
It runs on diesel; the engine is water-cooled. Within the range, rated power spans from 9.4 to 55.8 hp; with 55.8 hp, the CN59 sits at the top. Below it ranks the CT47HST with 47.7 hp.
Technical data
Engine
| Engine make | Mitsubishicorrect |
|---|---|
| Fuel | dieselcorrect |
| Power | 55.8 hp (41 kW)correct |
| Rated speed | 2,500 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,331.5 cm³correct |
| Bore | 94 mmcorrect |
| Stroke | 119.9 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,610 mmcorrect |
|---|---|
| Unladen weight | 2,520 kgcorrect |
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Gearbox type | synchro shuttlecorrect |
| Forward gears | 16correct |
| Reverse gears | 16correct |
| Forward gears | 16correct |
| Reverse gears | 16correct |
| Top speed | 27.8 km/hcorrect |
| Turning radius | 3,200 mmcorrect |
| System voltage | 12 Vcorrect |
Working data
| Lifting capacity | 1,760 kgcorrect |
|---|---|
| Pump flow | 36 l/mincorrect |
| Fuel tank capacity | 60.2 lcorrect |
| PTO output | 50 hpcorrect |
Origin and approval
| Plant | South Koreacorrect |
|---|
Other data
| Cab height | 2,438.4correct |
|---|
Where this model stands
Power-to-weight ratio: 16.3 kW/t (41 kW / 2.5 t)
Power class: Universal (40–100 hp)
Stronger than 39% of the tractors in the register — out of 15,143 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the McCormick CN59 have?
The McCormick CN59 delivers 55.8 hp.
How much does the McCormick CN59 weigh?
The unladen weight is 2,520 kg.
What engine does the McCormick CN59 have?
4 cylinders, 3,332 cm³ displacement, diesel.
How fast does the McCormick CN59 go?
Top speed is 27.8 km/h.
What is the PTO output of the McCormick CN59?
PTO output is 50 hp.
How much does the rear linkage of the McCormick CN59 lift?
The rear linkage lifts 1,760 kg.
When was the McCormick CN59 built?
Production years: 2010.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 31 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
Tractor in 3D section
Turn the model, look inside and click an assembly — each one is explained.
