Massey Ferguson 4609M Utility
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Massey Ferguson 4609M belongs to the Massey Ferguson Utility Tractor series. Under the bonnet works a three-cylinder engine displacing 3.3 litres, producing 91 hp (70.8 kW). Rated power is reached at 2,200 rpm.
Dimensions are 3.90 m by 2.05 m. Wheelbase is 2.29 m.
Within the range, rated power spans from 39 to 101 hp; with 91 hp, the 4609M sits in the upper third. Directly alongside are the MF4708 with 81.1 hp below and the 4609 with 91.2 hp above.
Technical data
Engine
| Engine make | AGCO Power™correct |
|---|---|
| Power | 91 hp (70.8 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 3,300.4 cm³correct |
| Aspiration | Intercooled turbochargedcorrect |
Dimensions and weights
| Length | 3,900.2correct |
|---|---|
| Width | 2,051.3correct |
| Wheelbase | 2,286correct |
Drivetrain and chassis
| Forward gears | 12correct |
|---|---|
| Reverse gears | 12correct |
Working data
| Pump flow | 66.2 l/mincorrect |
|---|---|
| Fuel tank capacity | 115.1 lcorrect |
Frequently asked questions
How much power does the Massey Ferguson 4609M have?
The Massey Ferguson 4609M delivers 91 hp.
What engine does the Massey Ferguson 4609M have?
3 cylinders, 3,300 cm³ displacement.
What are the dimensions of the Massey Ferguson 4609M?
3,900 mm × 2,051 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
