Marshall S-744
Built: 1988-1992 · Series: Other models
More machines from model year 1988
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Built in 1988-1992, the Marshall S-744 is a tractor from Marshall. The four-cylinder engine produces 54 kW.
Gearbox: Mechanical Gear; drive type: MFWD.
It runs on diesel; the engine is water-cooled. Within the range, rated power spans from 19 to 110 kW; with 54 kW, the S-744 sits in the mid-field. Directly alongside are the S-644 with 48 kW below and the 754 XL with 56 kW above.
Technical data
Engine
| Engine make | Steyrcorrect |
|---|---|
| Engine model | WD411.45correct |
| Fuel | dieselcorrect |
| Power | 72 hp (54 kW)correct |
| Cylinders | 4correct |
| Displacement | 3,456 cccorrect |
| Bore | 100correct |
| Stroke | 110correct |
| Turbocharger | yescorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Height | 2,380correct |
|---|---|
| Unladen weight | 2,870correct |
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Gearbox | mechanical gearbox Gearcorrect |
| Gearbox make | Steyr 337correct |
| Forward gears | 16correct |
| Reverse gears | 8correct |
| Clutch | Doublescorrect |
Origin and approval
| Plant | Austriacorrect |
|---|
Other data
| PTO speed | 540/ (750)/ 1000 (1250)correct |
|---|
Frequently asked questions
How much power does the Marshall S-744 have?
The Marshall S-744 delivers 72 hp.
What engine does the Marshall S-744 have?
4 cylinders, Diesel.
When was the Marshall S-744 built?
Production years: 1988-1992.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
