Marathon HGA280S-6

Series: Other models

The photo shows the CPVR75/CSD75IVR from the same series. Source: https://www.marathonelectric.in/product/TCAP753A3111GACD01

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The HGA280S-6 from Marathon is a three-phase induction motor. The rated output is 45 kW. The motor is six-pole, which at 50 Hz gives a synchronous speed of 1,000 rpm. The rated voltage is 400 V. The housing is frame size 280 S in foot-mounted form. The protection class is IP55. The efficiency is 93.5 per cent at full load, 93.1 per cent at 75 per cent load and 91.6 per cent at half load. The motor weighs 530 kg. At full load it delivers 433.2 Nm. The motor is built in China. The values are recorded in the Australian MEPS registration under the GEMS Determination 2019; measured to AS 1359.102.1:1997. Rated output across the Marathon range ranges from 0.75 to 160 kW; the HGA280S-6 sits in the lower part of that range with 45 kW. Its immediate neighbours are the XGA250M6 below it with 37 kW and the 250MTFC0552-AU above it with 55 kW. 498 Marathon models across 2 series are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.

Technical data

Engine

Rated output45 kWcorrect

Dimensions and weights

Weight530 kgcorrect

Electrical data

Rated voltage400 Vcorrect
Number of poles6correct
Protection classIP55correct
Frame size280 S (foot)correct
Mounting (IEC 60034-7)B3, B5, B6, B7, B8, B35, V1, V3, V5, V6correct
Efficiency at full load93.5 %correct
Efficiency at 75 % load93.1 %correct
Efficiency at half load91.6 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedGreenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct
Test methodAS 1359.102.1:1997correct

Frequently asked questions

How much power does the Marathon HGA280S-6 have?

The Marathon HGA280S-6 delivers 45 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
