Marathon CPC50/CSC50

Series: Other models

Source: https://www.finishers.com/de/articles/wie-viele-wochen-brauc

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Marathon CPC50/CSC50 is a three-phase induction motor built by Marathon. The rated output is 37 kW. The motor is two-pole, which at 50 Hz gives a synchronous speed of 3,000 rpm. The rated voltage is 400 V. The housing is frame size 200 L in foot-mounted form. The protection class is IP54. The efficiency is 93.3 per cent at full load, 93.4 per cent at 75 per cent load and 92.4 per cent at half load. The motor weighs 265 kg. At full load it delivers 120 Nm. The mounting arrangement to IEC 60034-7 is B3. The motor is built in China. The figures come from the Australian MEPS register under standard AS/NZS 1359.5:2004; measured to IEC 60034-2-1 (Edition 2.0). Rated output across the Marathon range ranges from 0.75 to 160 kW; the CPC50/CSC50 sits in the lower part of that range with 37 kW. Its immediate neighbours are the XGA225M6 below it with 30 kW and the 225MTFC0452-AU above it with 45 kW. 498 Marathon models across 2 series are on record. The model is listed under Electric motors. 24 verified figures from 1 source are on file.

Technical data

Engine

Rated output37 kWcorrect

Dimensions and weights

Weight265 kgcorrect

Electrical data

Rated voltage400 Vcorrect
Number of poles2correct
Protection classIP54correct
Frame size200 L (foot)correct
Mounting (IEC 60034-7)B3correct
Efficiency at full load93.3 %correct
Efficiency at 75 % load93.42 %correct
Efficiency at half load92.4 %correct

Origin and approval

Country of manufactureChinacorrect
Standard appliedAS/NZS 1359.5:2004correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the Marathon CPC50/CSC50 have?

The Marathon CPC50/CSC50 delivers 37 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
