Marathon 315LTFC1604E3
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Marathon – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, part of Regal Rexnord since 2021, frame sizes 80 to 355, 0.75 to 160 kW
This page gathers the Marathon three-phase motors the Australian energy-efficiency register could not assign to a named range. Marathon Electric, according to the company's own history founded in 1893 in Wausau, Wisconsin, now belongs to Regal Rexnord, the US drive-technology group formed in 2021 from the merger of Regal Beloit with parts of Rexnord. The identifiers in the register, such as 132STFC0552-AU or 160LTFC0758E3, recognisably start with the IEC frame size (132, 160), followed by letters for length and construction type and an output designation; the -AU suffix presumably marks a market variant certified specifically for Australia, E3 presumably a version in efficiency class IE3 – neither reading can be reliably confirmed from the dump alone.
Read on 3 more paragraphs
The register lists here 487 versions with 0.75 to 160 kW, two- to eight-pole, full-load efficiencies from 76 to 96.2% and at 75% load from 76.1 to 96.4%. Protection is mostly IP55 (344), in many cases extended with IP56 and IP66; frame sizes run from 80 to 355. China (477) dominates the manufacturing countries, with the USA, Chile, Colombia and Congo recorded singly. Testing mostly followed the 2019 GEMS determination (363) and AS/NZS 1359.5:2004 (115), with test method A for the majority; of 486 classified motors, 255 reach the 2005 High Efficiency Level (roughly IE2), 231 remain unclassified.
Marathon is one of the long-established US motor brands and today, within the Regal Rexnord group alongside brands such as Leeson and Rexnord, stands for drive technology in industry and building services; the range chiefly covers standard and pump motors for the North American and the Australia-Pacific markets.
When buying used, bearing condition and a checked insulation resistance of the winding, the condition of shaft and key, visible corrosion on the terminal box and fan cover, and a legible nameplate with frame size, pole count and, where present, the E3 mark for the efficiency class matter; on the many lots made exclusively in China, winding quality and bearing play are worth a look. Spares and service run through the Regal Rexnord network.
Sources: Kennwerte der Modelle Marathon (weitere Modelle, MEPS-Registrierungen)
Technical data
Engine
| Rated output | 160 kWcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55correct |
| Frame size | 315 L (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B35, V1, B14, B34correct |
| Efficiency at full load | 95.71 %correct |
| Efficiency at 75 % load | 96.1 %correct |
| Efficiency at half load | 95.3 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2004correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Marathon 315LTFC1604E3 have?
The Marathon 315LTFC1604E3 delivers 160 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
