Manitou MHT 10160

Series: Manitou Telescopic Forklift

Source: https://cn.baupool.com/details/%E4%BC%B8%E7%BC%A9%E8%87%82%E

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Manitou Telescopic Forklift series from Manitou includes the MHT 10160. The engine delivers 177.4 hp (130.5 kW), with a displacement of 4,244.2 cm³. Torque is 675.2 Nm. The unladen weight is 22,300.9 kg. The wheelbase measures 4,343.4 mm. The tank holds 196.8 litres. The gearbox has 2 forward gears. There are also 2 reverse gears. The pump delivers 170.3 l/min. The hydraulic tank holds 287.7 litres. Working pressure is 344.7 bar. The engine fitted is the OM 904 LA Turbo Diesel. Tyre size: 16,00R25. The Manitou Telescopic Forklift series covers 109 models. Rated output within it ranges from 40.3 to 216.3 hp; the MHT 10160 sits in the upper part of that range with 177.4 hp. Its immediate neighbours are the MHT 10120 L Turbo below it with 176.8 hp and the MHT 10130 above it with 178.4 hp. 759 Manitou models across 21 series are on record. The model is listed under Telehandlers. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine modelOM 904 LA Turbo Dieselcorrect
Power177.4 hp (130.5 kW)correct
Torque675.2correct
Displacement4,244.2 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Height2,920 mmcorrect
Wheelbase4,343.4correct
Unladen weight22,300.9 kgcorrect

Drivetrain and chassis

Gearbox typehydrostatic transmissioncorrect
Forward gears2correct
Reverse gears2correct
Tyre size16.00R25correct

Working data

Lift height9,680 mmcorrect
Pump flow170.3 l/mincorrect
Hydraulic oil capacity287.7 lcorrect
Hydraulic pressure344.7correct
Fuel tank capacity196.8 lcorrect

Where this model stands

Power-to-weight ratio: 5.9 kW/t (130 kW / 22.3 t)

Stronger than 97% of the telehandlers in the register — out of 661 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Manitou MHT 10160 have?

The Manitou MHT 10160 delivers 177 hp.

How much does the Manitou MHT 10160 weigh?

The unladen weight is 22,301 kg.

What engine does the Manitou MHT 10160 have?

4,244 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
