MAN TGS 26.440

Built: 2009-2011 · Series: TGS

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The MAN TGS 26.440 is a machine built by MAN. Production: 2009-2011. The engine delivers 324 kW, has 6 cylinders, with a displacement of 10,516 cm³. The machine is 10,640 mm long and 2,550 mm wide. The unladen weight is 8,430 kg. The wheelbase measures 6,450 mm. The gross vehicle weight is 26,000 kg. The machine runs on 6 wheels. Rated output across the MAN range ranges from 9.5 to 500 kW; the TGS 26.440 sits in the upper part of that range with 324 kW. Its immediate neighbours are the 35.480 8X4 BL below it with 323.5 kW and the TG-A (32,35).(463,483,513,533)FFD-8X4/180+251+140 above it with 327 kW. 3037 MAN models across 30 series are on record. The model is listed under Trucks over 7.5 t. 12 verified figures from 1 source are on file.

MAN TGS — heavy class, read the same way as TGL and TGM

The TGS follows the same rule as its smaller siblings: gross vehicle weight in tonnes before the dot, engine output in horsepower after it. A TGS 18.440 is rated at 18 tonnes and delivers 440 hp. Anyone who knows the TGL or TGM has nothing new to learn — only the class is different.

Read on 4 more paragraphs

The four abbreviations together form MAN's Trucknology Generation: TGL for the light class, TGM for the medium, TGS for the heavy and TGX for the heavy long-haul class. TGS and TGX share their engineering largely; what separates them is the cab and the layout. The TGS is the worker, the TGX the traveller.

The practical dividing line follows from that. Anyone running construction, tipper, silo, hooklift or heavy distribution work ends up with the TGS. Anyone sleeping in the vehicle night after night is better served by the TGX. Between the two it is not power that decides but the cab and frame design.

The axle configuration usually stands right after the type number: 4x2, 6x2, 6x4, 8x4. It says how many wheels there are and how many of them are driven. For site work it is the single most important figure — an 8x4 reaches places where a 4x2 stops, regardless of horsepower.

For used purchases the rule of all commercial vehicles applies: the type number gives weight and power but no year. Two TGS 18.440 can be a decade apart in emissions stage, gearbox and equipment. What decides is first registration and emissions standard.

Sources: MAN: Guidelines for Fitting Bodies TGS/TGX, MAN Trucknology Generation TGS/TGX

Technical data

Engine

Power324 kWcorrect
Cylinders6correct
Displacement10,516 cm³correct

Dimensions and weights

Length10,640 mmcorrect
Width2,550 mmcorrect
Wheelbase6,450 mmcorrect
Unladen weight8,430 kgcorrect
Gross vehicle weight26,000 kgcorrect

Drivetrain and chassis

Wheels6correct

Where this model stands

Power-to-weight ratio: 38.4 kW/t (324 kW / 8.4 t)

Stronger than 65% of the trucks over 7.5 t in the register — out of 25,442 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the MAN TGS 26.440 have?

The MAN TGS 26.440 delivers 324 kW.

How much does the MAN TGS 26.440 weigh?

The unladen weight is 8,430 kg.

What is the gross vehicle weight of the MAN TGS 26.440?

26,000 kg.

What engine does the MAN TGS 26.440 have?

6 cylinders, 10,516 cm³ displacement.

What are the dimensions of the MAN TGS 26.440?

10,640 mm × 2,550 mm.

When was the MAN TGS 26.440 built?

Production years: 2009-2011.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 12 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
