Kuiper K5403Z
Built: 2002-2002 · Series: Trailers 3.5–10 t (Class O3)
More machines from model year 2002
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Kuiper Anhänger 3,5–10 t (Class O3) – Dutch mid-weight trailers, KD range, 1.25 to 8.1 t kerb weight, up to 10 t gross weight
Class O3 covers trailers from 3.5 to 10 t gross vehicle weight – the mid-weight class between light car trailers (O2) and heavy semi-trailers (O4). Kuiper is a Dutch builder of such trailers whose core range is the "KD" series; the following number (such as KD6002, KD7402, KD9005) presumably denotes the gross vehicle weight in kilograms, while suffixes such as "VK" or "Z" mark body or axle variants.
Read on 3 more paragraphs
The register lists 88 versions with kerb weights from 1,250 to 8,080 kg, gross vehicle weights from 3,990 to 10,000 kg, lengths from 5,130 to 13,850 mm and widths from 1,600 to 2,550 mm.
Trailers of this weight class require a towing vehicle with a matching towing capacity and usually a BE or C1E licence category; they serve in construction, landscaping and transport for loads too heavy for an O2 trailer but not requiring a semi-trailer.
Used, what counts is the condition of axles, braking system and overrun device, frame cracks at heavily loaded attachment points, the condition of ramps or side boards depending on the body, and the function of the lighting system; spare parts are available through the Dutch and neighbouring specialist trade.
Sources: Kennwerte der Modelle Kuiper Anhänger 3,5–10 t (Klasse O3)
Technical data
Dimensions and weights
| Length | 9,150 mmcorrect |
|---|---|
| Width | 2,450 mmcorrect |
| Wheelbase | 5,190 mmcorrect |
| Unladen weight | 4,260 kgcorrect |
| Gross vehicle weight | 5,400 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Kuiper K5403Z weigh?
The unladen weight is 4,260 kg.
What is the gross vehicle weight of the Kuiper K5403Z?
5,400 kg.
Up to what speed is the Kuiper K5403Z approved?
Approved up to 100 km/h.
What are the dimensions of the Kuiper K5403Z?
9,150 mm × 2,450 mm.
When was the Kuiper K5403Z built?
Production years: 2002.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
