Kraker CF-X
Built: 2015-2021 · Series: Other models
More machines from model year 2015
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Kraker – other models: the collective page of the Dutch walking-floor trailers outside the named ranges, CF range, 5.9 to 11 t unladen weight, up to 51 t gross weight
This page gathers the Kraker trailers the register could not assign to a named range – walking-floor trailers from the Dutch manufacturer Kraker Trailers. The type designation CF carries the range, suffixes such as -S, -X, -Z, -C or -TD distinguish equipment variants of the moving floor and the sides; the code AHW in the model name CF-AHW stands for the Dutch aanhangwagen, trailer, marking the version built as a drawbar trailer instead of a semi-trailer.
Read on 3 more paragraphs
The register lists here 30 versions with unladen weights from 5,860 to 11,020 kg, gross weights from 24,000 to 51,000 kg, lengths from 9,550 to 14,040 mm and widths from 2,540 to 2,600 mm.
Walking-floor trailers unload bulk goods such as grain, feed, compost or recycling material on their own via a hydraulically driven floor, without needing to tip; Kraker is regarded in this market segment as one of the manufacturers with the widest reach in north-west Europe, with approvals reaching the high combination weights of the Netherlands and Scandinavia.
On used trailers of this kind, the condition of the moving-floor slats and chains, the tightness of the sides, the hydraulic cylinders and lines of the floor drive, axles and brakes, and the frame and kingpin for wear all count; spare parts for the moving floor run through Kraker itself.
Sources: Kennwerte der Modelle Kraker (weitere Modelle), Kraker Trailers (Hersteller), RDW (Niederlande)
Technical data
Dimensions and weights
| Length | 14,010 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 10,110 mmcorrect |
| Unladen weight | 11,020 kgcorrect |
| Gross vehicle weight | 48,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Kraker CF-X weigh?
The unladen weight is 11,020 kg.
What is the gross vehicle weight of the Kraker CF-X?
48,000 kg.
Up to what speed is the Kraker CF-X approved?
Approved up to 100 km/h.
What are the dimensions of the Kraker CF-X?
14,010 mm × 2,550 mm.
When was the Kraker CF-X built?
Production years: 2015-2021.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
