Komatsu FG25SHT-14
Series: Komatsu Forklift
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Komatsu forklifts FD, FG, FB and FS – the type code: D for diesel, G for LPG, B for battery, the number as capacity, up to the 16-tonne FD160E, with Mitsubishi Logisnext since 2017
Komatsu built forklifts from 1955 at its Tochigi plant and was for decades one of the big Japanese suppliers; in 2017 the forklift business merged into Mitsubishi Logisnext, the combination of the forklift divisions of Mitsubishi, Nichiyu, TCM and Unicarriers. The type code is a formula that appears line by line in the register: F for Forklift, the second letter for the drive – D diesel, G gas (gasoline/LPG), B battery, S and R for reach trucks and warehouse equipment – the number for the capacity in hundreds of kilograms (FD25 carries 2.5 t, FD160 16 t), then equipment letters: S for the standard version, H for high performance, T for the torque-converter version, M for the compact electric layout, E for the reinforced heavy-truck version; the digit after the hyphen gives the generation, -7, -8, -14 and -17 on the combustion trucks, -3 and -6 on the electrics.
Read on 3 more paragraphs
The register lists 38 versions with capacities from 1,134 to 15,876 kg, service weights from 2,695 to 17,051 kg and widths from 966 to 2,481 mm; the combustion trucks have four- and six-cylinders of 2,065 to 6,489 cm³ – Nissan K21 and K25, TB45 and Isuzu 6BG1 in the heavy trucks – at 1,950 to 2,950 rpm, the electrics run on 36 V.
The FD100 to FD160 are the heavy trucks for ports, steel and timber, the FB and FS models the indoor machines; Komatsu's forklifts shared engines with Nissan and Isuzu, which eases parts supply today.
On used trucks, operating hours, play in the mast, the condition of chains and forks, battery age and charge cycles on electrics and, on combustion trucks, the availability of engine parts through Nissan, Isuzu and Logisnext dealers are what count.
Sources: Kennwerte der Modelle Komatsu Gabelstapler, Mitsubishi Logisnext (Rechtsnachfolger Komatsu Forklift)
Technical data
Engine
| Engine model | K25correct |
|---|---|
| Fuel | petrolcorrect |
| Rated speed | 2,900 rpmcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,490.8 cm³correct |
Dimensions and weights
| Width | 1,060.7correct |
|---|---|
| Wheelbase | 1,402.1correct |
| Ground clearance | 105.2correct |
| Unladen weight | 3,710.4 kgcorrect |
Drivetrain and chassis
| Tyre type | cushion tyrescorrect |
|---|---|
| Top speed | 16.6 km/hcorrect |
| Turning radius | 1,970 mmcorrect |
Working data
| Lifting capacity | 2,268 kgcorrect |
|---|---|
| Lift height | 3,250 mmcorrect |
Other data
| Lift speed | 36.6 m/mincorrect |
|---|---|
| Load centre | 600.2 mmcorrect |
| Mast tilt back | 10°correct |
| Mast tilt forward | 6°correct |
More machines with this engine (Nissan K25, 26)
Frequently asked questions
How much does the Komatsu FG25SHT-14 weigh?
The unladen weight is 3,710 kg.
What engine does the Komatsu FG25SHT-14 have?
4 cylinders, 2,491 cm³ displacement, Gasoline.
How fast does the Komatsu FG25SHT-14 go?
Top speed is 16.6 km/h.
What is the load capacity of the Komatsu FG25SHT-14?
Load capacity is 2,268 kg at a 600 mm load centre, lift height 3,250 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
