Komatsu D85A-21 Crawler

Series: Other models

Source: https://www.truck1.eu/leasing/forestry-equipment/from-latvia

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Komatsu Crawler Tractor series from Komatsu includes the D85A-21. The engine delivers 231.2 hp (170 kW), has 6 cylinders, with a displacement of 15,241.6 cm³. Torque is 999.6 Nm. Rated speed is 2,000 rpm. The unladen weight is 24,440 kg. Ground clearance is 417.6 mm. The tank holds 480.4 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 194.2 l/min. Working pressure is 191.2 bar. The cooling system holds 79.1 litres. The oil fill is 27.3 litres. The electrical system runs on 24 V. The engine fitted is the S6D125E. The Komatsu Crawler Tractor series covers 265 models. Rated output within it ranges from 35.5 to 4,126.5 hp; the D85A-21 sits at the bottom of that range with 231.2 hp. Its immediate neighbours are the D85E-21 below it with 228.1 hp and the D87E-3 above it with 250.4 hp. 1159 Komatsu models across 39 series are on record. The model is listed under Mining equipment. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine modelS6D125Ecorrect
Power231.2 hp (170 kW)correct
Rated speed2,000 rpmcorrect
Torque999.6correct
Speed at max. torque1,400 rpmcorrect
Cylinders6correct
Displacement15,241.6 cm³correct
Aspirationturbochargedcorrect
Coolant capacity79.1 lcorrect
Engine oil capacity27.3 lcorrect

Dimensions and weights

Ground clearance417.6correct
Unladen weight24,440 kgcorrect

Drivetrain and chassis

Gearbox typeTFcorrect
Forward gears3correct
Reverse gears3correct
System voltage24 Vcorrect

Working data

Pump flow194.2 l/mincorrect
Hydraulic pressure191.2correct
Fuel tank capacity480.4 lcorrect

Other data

Height3,380.2correct

Where this model stands

Power-to-weight ratio: 7 kW/t (170 kW / 24.4 t)

Stronger than 60% of the mining equipment in the register — out of 945 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Komatsu D85A-21 have?

The Komatsu D85A-21 delivers 231 hp.

How much does the Komatsu D85A-21 weigh?

The unladen weight is 24,440 kg.

What engine does the Komatsu D85A-21 have?

6 cylinders, 15,242 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
