Komatsu D475A-5 Tier 2 Crawler

Series: Other models

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Komatsu Crawler Tractor series from Komatsu includes the D475A-5 Tier 2. The engine delivers 911.5 hp (663.7 kW), has 12 cylinders, with a displacement of 30,479.9 cm³. The unladen weight is 113,198.5 kg. Ground clearance is 661.4 mm. The tank holds 1,669.4 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. Working pressure is 274.4 bar. The cooling system holds 210.1 litres. The oil fill is 121.1 litres. The engine fitted is the SAA12V140E-3. The Komatsu Crawler Tractor series covers 265 models. Rated output within it ranges from 35.5 to 4,126.5 hp; the D475A-5 Tier 2 sits in the lower part of that range with 911.5 hp. Its immediate neighbours are the D475A-3 below it with 884.1 hp and the D575A-2 above it with 1,079.8 hp. 1159 Komatsu models across 39 series are on record. The model is listed under Mining equipment. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine modelSAA12V140E-3correct
Power911.5 hp (663.7 kW)correct
Cylinders12correct
Displacement30,479.9 cm³correct
Aspirationturbocharged, air-to-air aftercooledcorrect
Coolant capacity210.1 lcorrect
Engine oil capacity121.1 lcorrect

Dimensions and weights

Ground clearance661.4correct
Unladen weight113,198.5 kgcorrect

Drivetrain and chassis

Gearbox typeKomatsu TORQFLOW transmissioncorrect
Forward gears3correct
Reverse gears3correct

Working data

Hydraulic pressure274.4correct
Fuel tank capacity1,669.4 lcorrect

Other data

Cab height4,648.2correct

More machines with this engine (SAA12V140E-3, 5)

Where this model stands

Power-to-weight ratio: 5.9 kW/t (664 kW / 113.2 t)

Stronger than 95% of the mining equipment in the register — out of 944 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Komatsu D475A-5 Tier 2 have?

The Komatsu D475A-5 Tier 2 delivers 912 hp.

How much does the Komatsu D475A-5 Tier 2 weigh?

The unladen weight is 113,198 kg.

What engine does the Komatsu D475A-5 Tier 2 have?

12 cylinders, 30,480 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
