Komatsu D375A-3 Crawler

Series: Other models

Source: https://www.komatsu.eu/en/Crawler-Dozers/D375A-8 komatsu.eu

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Komatsu Crawler Tractor series from Komatsu includes the D375A-3. The engine delivers 539.4 hp (396.7 kW), has 6 cylinders, with a displacement of 23,150 cm³. Rated speed is 1,800 rpm. The unladen weight is 68,200 kg. Ground clearance is 621.8 mm. The tank holds 1,050.1 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. The pump delivers 255.1 l/min. Working pressure is 205.9 bar. The cooling system holds 136.3 litres. The oil fill is 51.1 litres. The electrical system runs on 24 V. The engine fitted is the S6D170E-2. The Komatsu Crawler Tractor series covers 265 models. Rated output within it ranges from 35.5 to 4,126.5 hp; the D375A-3 sits at the bottom of that range with 539.4 hp. Its immediate neighbours are the D375A-1 below it with 522.1 hp and the D375A-5 above it with 613.4 hp. 1159 Komatsu models across 39 series are on record. The model is listed under Mining equipment. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelS6D170E-2correct
Power539.4 hp (396.7 kW)correct
Rated speed1,800 rpmcorrect
Cylinders6correct
Displacement23,150 cm³correct
Aspirationturbochargedcorrect
Coolant capacity136.3 lcorrect
Engine oil capacity51.1 lcorrect

Dimensions and weights

Ground clearance621.8correct
Unladen weight68,200 kgcorrect

Drivetrain and chassis

Gearbox typeTFcorrect
Forward gears3correct
Reverse gears3correct
System voltage24 Vcorrect

Working data

Pump flow255.1 l/mincorrect
Hydraulic pressure205.9correct
Fuel tank capacity1,050.1 lcorrect

Other data

Height4,230.6correct

Where this model stands

Power-to-weight ratio: 5.8 kW/t (397 kW / 68.2 t)

Stronger than 88% of the mining equipment in the register — out of 945 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Komatsu D375A-3 have?

The Komatsu D375A-3 delivers 539 hp.

How much does the Komatsu D375A-3 weigh?

The unladen weight is 68,200 kg.

What engine does the Komatsu D375A-3 have?

6 cylinders, 23,150 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
