Jumbo TV280 KE
Built: 2006-2006 · Series: TV280
More machines from model year 2006
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Jumbo TV280 – low-loader range from the Dutch maker Jumbo: eight versions with 28 tonnes gross weight, 5,260 to 8,400 kg unladen weight, 9.17 to 10.76 m length
The TV280 range brings together low-loader trailers from the Dutch manufacturer Jumbo, which specialises in low-loaders for transporting construction machinery and vehicles. The model list shows the shared base designation TV280 with the suffixes KE, L, L1, LC1, LUE, R and ZCE, which mark different body and equipment variants of the same base design.
Read on 3 more paragraphs
The register lists 8 versions with unladen weights from 5,260 to 8,400 kg at a uniform gross weight of 28,000 kg. Lengths range from 9,170 to 10,760 mm, widths from 2,500 to 2,600 mm.
With a gross weight of 28 tonnes, the TV280 range covers the mid segment of low-loaders used in the Netherlands and neighbouring central Europe to transport excavators, wheel loaders and other working machines; typical buyers are construction firms, machinery rental companies and hauliers specialising in construction-machinery transport.
When buying a used trailer of this range, particular attention should go to the condition and ease of movement of the loading ramps and to the tightness and function of the hydraulic cylinders on lowering versions. The frame and loading deck should be checked for rust and deformation, as should axles, brakes and lashing points; tyres and lighting belong to the standard check. Spare parts for axles and brakes are supplied by the general commercial-vehicle parts trade.
Sources: Kennwerte der Modelle Jumbo TV280
Technical data
Dimensions and weights
| Length | 9,700 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 5,560 mmcorrect |
| Unladen weight | 5,980 kgcorrect |
| Gross vehicle weight | 28,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Jumbo TV280 KE weigh?
The unladen weight is 5,980 kg.
What is the gross vehicle weight of the Jumbo TV280 KE?
28,000 kg.
Up to what speed is the Jumbo TV280 KE approved?
Approved up to 100 km/h.
What are the dimensions of the Jumbo TV280 KE?
9,700 mm × 2,550 mm.
When was the Jumbo TV280 KE built?
Production years: 2006.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
