Jumbo EO 100 Z 3
Built: 1978-1978 · Series: EO
More machines from model year 1978
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Jumbo EO – other models: the collective page of the EO range of heavy trailers outside the named types, weight classes 60 to 153, 1.9 to 17.7 t unladen weight, up to 27 t gross weight
This page gathers the Jumbo EO-range trailers the register could not assign to a named version. The type plates consistently consist of the prefix EO followed by a number from 60 to around 153, which by the manufacturer's logic names the weight or payload class; suffixes such as Z, S, SE, VZE and the digits after them (Z 11, Z 13) denote axle count and equipment variant, W and C further body forms.
Read on 3 more paragraphs
The register lists here 42 versions with unladen weights from 1,900 to 17,660 kg, gross weights from 8,000 to 27,000 kg and widths from 2,380 to 2,600 mm; these values place the whole EO range in vehicle class O4 (over 10 t) for heavy trailers.
Trailers of this weight class are used in haulage and agriculture for bulk goods, bales and heavy loads, with the EO range covering the mid to upper weight class between light tandem-axle trailers and semi-trailers. The number on the type plate lets the weight class be read off the trailer itself, without having to check the papers.
When buying used, what matters is rust and cracks in the chassis, the condition of axles and brake system, the function of the lighting and the condition of the tyres, and, on versions with hydraulic tipping, the condition of the ram and tipping mechanism; a valid roadworthiness inspection and, on the heaviest versions, a complete service history are prerequisites. Spares run through the Jumbo distribution network and the common commercial-vehicle suppliers.
Sources: Kennwerte der Modelle Jumbo EO
Technical data
Dimensions and weights
| Length | 9,820 mmcorrect |
|---|---|
| Width | 2,380 mmcorrect |
| Wheelbase | 6,500 mmcorrect |
| Unladen weight | 3,946 kgcorrect |
| Gross vehicle weight | 17,000 kgcorrect |
Drivetrain and chassis
| Wheels | 2correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Jumbo EO 100 Z 3 weigh?
The unladen weight is 3,946 kg.
What is the gross vehicle weight of the Jumbo EO 100 Z 3?
17,000 kg.
Up to what speed is the Jumbo EO 100 Z 3 approved?
Approved up to 100 km/h.
What are the dimensions of the Jumbo EO 100 Z 3?
9,820 mm × 2,380 mm.
When was the Jumbo EO 100 Z 3 built?
Production years: 1978.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
