John Deere 772BH

Series: John Deere Motor Grader

Source: https://www.tractordata.com/farm-tractors/005/2/3/5234-john-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere 772BH belongs to the John Deere Motor Grader series. The engine has 6 cylinders, with a displacement of 7,638 cm³. Rated speed is 2,200 rpm. The machine is 8,510 mm long. The unladen weight is 16,683.1 kg. The wheelbase measures 5,971 mm. Ground clearance is 579.1 mm. The tank holds 340.3 litres. Maximum torque is reached at 1,100 rpm. The hydraulic tank holds 87.1 litres. The cooling system holds 38.2 litres. The electrical system runs on 24 V. The engine fitted is the 6076A. Tyre size: 14,00-24. The John Deere Motor Grader series covers 35 models. Unladen weight within it ranges from 8,210 to 22,053.7 kg; the 772BH sits in the upper part of that range with 16,683.1 kg. Its immediate neighbours are the 772B below it with 16,660.4 kg and the 672CH above it with 16,805.6 kg. 2153 John Deere models across 96 series are on record. The model is listed under Motor graders. 16 verified figures from 1 source are on file.

Technical data

Engine

Engine model6076Acorrect
Rated speed2,200 rpmcorrect
Speed at max. torque1,100 rpmcorrect
Cylinders6correct
Displacement7,638 cm³correct
Aspirationturbochargedcorrect
Coolant capacity38.2 lcorrect

Dimensions and weights

Length8,510correct
Wheelbase5,971correct
Ground clearance579.1correct
Unladen weight16,683.1 kgcorrect

Drivetrain and chassis

Gearbox typePower Shiftcorrect
Tyre size14.00-24correct
System voltage24 Vcorrect

Working data

Hydraulic oil capacity87.1 lcorrect
Fuel tank capacity340.3 lcorrect

Frequently asked questions

How much does the John Deere 772BH weigh?

The unladen weight is 16,683 kg.

What engine does the John Deere 772BH have?

6 cylinders, 7,638 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
